SHEHDS WZMH3618F - 36x18W RGBWA+UV Wash & Zoom Moving Head (Touch Screen)

SHEHDS WZMH3618F – Moving Head Wash & Zoom 36×18W RGBWA+UV

The SHEHDS WZMH3618F moving head features 36 x 18W LEDs in a 6-in-1 RGBWA+UV configuration, delivering intense colors and UV effects for vibrant environments. It features a 15° to 45° motorized zoom and a 15° fixed angle for wide washes, with a 0–100% linear dimmer and 0–20 Hz strobe. DMX512 control in 12 or 18-channel modes, 540°/270° pan/tilt, and a rugged housing designed for clubs, weddings, and professional stages. Its universal power supply (AC 100–240 V) and passive heatsink ensure reliability and quiet operation.

Main features

• Light source: 36 × 18 W RGBWA + UV 6-in-1 LEDs
• Motorized zoom: 15°–45°
• Beam angle (fixed): 15°
• Dimmer: 0–100% linear
• Strobe: 0–20 Hz
• DMX512 Channels: 12/18
• Movement: Pan 540° / Tilt 270°
• Power supply: AC 100–240 V, 50/60 Hz; consumption 520 W
• Housing: Fireproof technical plastic, passive dissipation
• Dimensions: 34.8 × 21.9 × 45 cm
• Net weight: 7.55 kg

Product benefits

• Chromatic versatility: Includes UV channel for special effects along with RGBWA.
• Precise control: Motorized zoom and wide pan/tilt to cover any angle.
• Professional Quality: Adjustable linear dimmer and strobe for smooth transitions.
• Agile installation: Universal power supply and cascade DMX control.
• Silent operation: Passive dissipation without noisy fans.

Use cases

• Lighting dance floors in discos and clubs.
• Setting for weddings, banquets and social events.
• Small and medium-sized theater productions and concerts.
• Corporate shows and audiovisual presentations.
• Permanent installations in bars, lounges and restaurants.

Frequently Asked Questions

• How do I switch between wash and beam? Using dedicated DMX channels or from the onboard control menu.
• Can I chain multiple units together? Yes; it supports serial DMX and PowerCON in/out connections.
• Do the fans require maintenance? No; their passive cooling design eliminates moving parts.
• What is the LED lifespan? Over 60,000 hours of continuous use.

Description for projects

36×18W RGBWA+UV Wash & Zoom moving head, 15°–45° zoom, 15° fixed beam, linear dimmer, 0–20 Hz strobe, DMX512 12/18 ch, pan 540°/tilt 270°, 520W power consumption, AC 100–240V, flame-retardant housing, 34.8×21.9×45 cm, 7.55 kg.
