Electro-Voice RE3-HHT96-5H - UHF Handheld Transmitter with ND96 Supercardioid Dynamic Capsule (560–596 MHz)

Electro-Voice RE3-HHT96-5H - UHF Handheld Transmitter with ND96 Supercardioid Dynamic Capsule (560–596 MHz)

The Electro-Voice RE3-HHT96-5H combines the RE3-HHT bodypack with the ND96-RC3 headshell to deliver a wireless handheld microphone that’s ready for high-volume performance. The ND96 capsule is a dynamic supercardioid with exceptional gain-before-feedback and a Presence Boost switch allows for a flat or vocal-emphasized response to cut through the mix. The transmitter operates in the 5H band (560–596 MHz) with a 36 MHz tuning width and selectable 10/50 mW RF power , making it easy to coordinate frequencies for touring, theatrical, and corporate events.

The RE3-HHT has a metal body , LCD + LED display , ultrasonic synchronization with the receiver for immediate tuning and a standard 1.25 "-28 threaded coupling ( 3 rings / 3 pin contact) that accepts EV heads and other brands with the same standard. It works with 2 AA batteries (alkaline or NiMH) and incorporates charging contacts compatible with the RE3-ACC-BC2 charger for in-situ NiMH recharging.

Main features

• Band 5H (560–596 MHz) with 36 MHz tuning and 1,440 selectable frequencies .
• Switchable RF power : 10 or 50 mW (depending on band).
• ND96 supercardioid dynamic microphone with presence switch , Memraflex grille , advanced shock-mount , hydrophobic membrane and humbucking coil .
• Ultrasonic synchronization with the RE3 receiver for fast frequency copying and settings.
• Interface : LCD + LED display; controls for power, mute, group/channel, frequency, sensitivity, RF power, auto-off, and key lock.
• Professional construction : metal body, black polyurethane finish, 1.25″-28 threaded coupling (3 rings/3 pins).

Product benefits

• Maximum intelligibility in noisy environments thanks to the ND96's supercardioid directivity and switchable presence boost.
• Agile deployment : fast scanning and synchronization, selectable RF power and wide tuning range (36 MHz).
• Reliability under intensive use: metal body, sturdy grille and internal suspension to reduce handling noise.
• Versatility : Interchangeable heads EV (ND/RE Series) or others with standard 1.25″-28 / 3 rings-3 pins.

Use cases

• Lead vocals and backing vocals in pop/rock/metal with close monitors and high levels.
• Corporate events, MCs and presenters that require high rejection from the environment.
• Mobile production and technical rental with multi-channel racks based on the RE3 series.

Description for projects

RE3-HHT UHF Handheld Transmitter with ND96-RC3 Head. 5H band: 560–596 MHz; tuning width: 36 MHz; selectable frequencies: 1,440; RF power: 10/50 mW. Modulation: Wideband FM (±48 kHz); RF stability: <±10 kHz; synchronization: Ultrasonic. Power: 2×AA (alkaline or NiMH); charging contacts compatible with RE3-ACC-BC2 . Head coupling: 1.25″-28 thread, 3-ring/3-pin contact. Body dimensions (without head): 191 mm (length) × 37 mm (thread Ø) / 22 mm (control coverage); body weight (without head): 346 g. ND96 Head: Supercardioid dynamic; Response 30 Hz–15 kHz (near) / 140 Hz–15 kHz (far); sensitivity 4.7/3.2 mV/Pa (flat/presence); max. SPL 136.5 dB; dimensions: 83.5 mm × 50.5 mm; weight: 193 g.
