beamZ PS10W - 10W RGBW LED Pin Spot with DMX and Narrow Beam for Mirror Balls
The beamZ PS10W is a compact and powerful pin spot that integrates a 10W 4-in-1 RGBW LED , mixing red, green, blue, and white to create everything from saturated colors to a pure white. Thanks to its narrow 10° beam angle and 11° field of view , it focuses light precisely, making it especially effective for illuminating mirror balls and other specific objects, producing thousands of defined flashes. It offers DMX control (4 or 7 channels) and autonomous operation via automatic programs or music-activated settings . It allows you to set a static color or cycle through colors sequentially, and also features a last-setting memory : when the spotlight is switched back on, it recalls the last setting.
Its special optics concentrate the light output to reach up to 1,670 lx at 1 meter , and its robust black design includes a handle/mounting bracket for quick installation on trusses, ceilings, or walls. It features DMX in/out via 3-pin XLR for daisy-chaining, a fixed power cable , an IP20 rating for indoor use, and an efficient power consumption of 17 W. Its compact dimensions (150 x 68 x 145 mm) and weight of 0.7 kg facilitate its integration into DJ booths, mobile stages, and events where space is at a premium.
Main features
-
Light source: 1 x 10W RGBW LED (4-in-1)
-
Color mixing: RGBW with real white for natural tones
-
Precision optics: beam angle 10° / field angle 11°
-
Output: 1,670 lux at 1 m
-
Control modes: DMX (4 or 7 channels), automatic programs and audio (sound)
-
Memory: remembers the last setting after turning off/on
-
Connectivity: DMX in/out 3-pin XLR; master/slave operation
-
Mounting: Includes handle/fixing bracket
-
Power supply: 100–240 V AC, 50/60 Hz, 17 W consumption, fixed network cable
-
Indoor use: IP20, black color
-
Compact format: 150 x 68 x 145 mm; 0.7 kg
Product benefits
-
Sharp and defined beam: the 10° angle focuses the light where you need it, maximizing the effect on mirror balls and point decorations.
-
Authentic white + vivid colors: the 4-in-1 RGBW LED allows for clean whites and uniform color mixing without multi-colored shadows.
-
Control flexibility: immediate integration into DMX installations or standalone use without a console.
-
Energy efficiency: only 17W consumption, ideal for long-term installations and systems with multiple units.
-
Quick installation: included bracket, lightweight format and daisy-chainable DMX connections.
-
Agile operation: last state memory to save time between sessions.
Use cases
-
Mirror balls and dance floor centers in clubs, bars and event venues.
-
Occasional decoration for weddings, presentations and fairs (centerpieces, columns, logos).
-
Window displays and brand activations that require precise lighting accents.
-
Theatre and shows as a specific fill, marking of elements or retro/disco effects.
Frequently Asked Questions
Can it work without a DMX controller?
Yes, it includes automatic programs and a sound-activated mode. It also allows you to set a static color.
Does it include a mounting bracket?
Yes, it comes with a handle/support for fixing to a truss or suitable surface.
Can multiple units be chained together?
Yes, it has DMX in/out with 3-pin XLR connectors for master/slave linking and operation.
Do you remember the last setting you made when you turned it off?
Yes, the light bulb memorizes the last state and retrieves it when turned on.
Is it suitable for outdoor use?
No, its IP20 rating is for indoor use.
Installation and control
-
DMX channels: 4 or 7, to control color, macros and programs according to configuration.
-
Master/slave: synchronizes multiple controllerless units.
-
Safety: We recommend using an additional safety cable when mounting at height.
Project description
Indoor LED pin spot with 1 x 10W 4-in-1 RGBW LED; RGBW mixing; 10° beam angle and 11° field of view; 1,670 lx @ 1 m illuminance; automatic, audio and DMX (4/7 channels) modes; 3-pin XLR DMX in/out; last state memory; 100–240V AC, 50/60Hz power supply; 17W consumption; IP20; black color; fixed power cable; includes mounting bracket; dimensions 150 x 68 x 145 mm; weight 0.7 kg.
