JBL PROFESSIONAL

JBL Professional SCS-8 - 2-way coaxial surround speaker with 8" woofer for home theater and immersive installations

Out of stock
SKU: SCS-8 EAN13: 50036904377
(0)
964,40 € inc. VAT

If you have any questions about this product, we can assist you by filling out the contact form

Ask an expert

Chat Email +34 621046470
The SCS 8 is a 2-way, coaxial-driver, full-range surround theater speaker ideal for multi-channel surround sound formats and is designed for both in-ceiling and standard in-wall installations. Features: 250 watts of power handling (average continuous pink noise) with high sensitivity provides high SPL capability. Consistent control of the 120° x 120° wideband pattern for outstanding cinema surround sound with extended frequency response for special effects. Components: 200 mm (8 in) Kevlar-reinforced woofer and 50 mm (2 in) voice coil and cone. 25 mm (1 in) exit compression driver with unique patented design and high temperature polymer diaphragm. 70 Hz - 20 kHz frequency response. High-power passive crossover network. Overload protection
  • Brand:JBL Professional
  • Model:SCS-8
  • Guy:Full-range surround speaker for cinema/installations
  • Tracks / Design:2-way, coaxial
  • Nominal coverage (-6 dB):120° (H) x 120° (V) conical
  • Frequency range (-10 dB):70 Hz – 20 kHz
  • Frequency response (±3 dB):90 Hz – 20 kHz
  • Sensitivity (2.83 V/1 m):94 dB (average 90 Hz–20 kHz)
  • Maximum SPL (1 m):118 dB (peaks 124 dB)
  • Permissible power (AES 2 h / 100 h):250 W / 200 W
  • Nominal impedance:8 Ω
  • Minimum impedance:5.3 Ω @ 190 Hz
  • Crossover Frequency / Topology:2.1 kHz; HF 3rd order (18 dB/oct) + conjugate, LF 2nd order (12 dB/oct)
  • LF Transducer:1 × 200 mm (8") with Kevlar reinforced cone, 50 mm coil
  • HF Transducer:1 × 25 mm (1") (25 mm diaphragm and coil), patented design, fluid cooling
  • HF Protection:SonicGuard™ Minimum Audibility
  • Directivity factor (Q):8.1 (1–16 kHz)
  • Directivity Index (DI):8.4 dB (1–16 kHz)
  • Construction of the enclosure:ABS with fiberglass, strongly braced
  • Rack:Zinc-rich coated steel (anti-corrosion)
  • Input connection:CE-covered terminal block; accepts bare wire or spatulas/forks, up to 2.5 mm²
  • Fixing points:2 × M10 for U-bracket; M6 secondary point for safety
  • Included accessories:Steel U-bracket
  • U-bracket rotation angle:±90°
  • Color:Black
  • Dimensions (H × W × D):300 × 300 × 305 mm
  • Depth with bracket included:359 mm
  • Net weight:8.2 kg (10.0 kg with stand)
  • Shipping weight:11.4 kg
  • Type New
  • Vendor JBL PROFESSIONAL
  • SKU SCS-8
  • Bar-code 50036904377

Buy JBL Professional SCS-8 - 2-way coaxial surround speaker with 8" woofer for home theater and immersive installations
