JBL Professional SCS-12 - 2-way coaxial surround speaker with 12" woofer for home theater and immersive installations

Out of stock
SKU: SCS-12 EAN13: 50036904384
(0)
1.530,87 € inc. VAT

If you have any questions about this product, we can assist you by filling out the contact form

Ask an expert

Chat Email +34 621046470
The SCS 12 is a two-way, full-range surround theater speaker with a coaxial driver, ideal for multi-channel surround sound formats and designed for both in-ceiling and standard in-wall installations. Features: 400 watts of power handling (average continuous pink noise) with high sensitivity provides high SPL capability. Consistent 100° x 100° wideband pattern provides outstanding clarity with extended frequency response for special effects. Components: 300 mm (12 in) woofer with Kevlar reinforcement cone and 75 mm (3 in) voice coil. 25 mm (1 in) exit compression driver with unique patented design and high temperature polymer diaphragm. High-power passive crossover network Overload protection
  • Brand:JBL Professional
  • Model:SCS-12
  • Guy:Full-range surround speaker for cinema/installation
  • Tracks / Design:2-way, coaxial
  • Nominal coverage (-6 dB):100° (H) x 100° (V)
  • Frequency range (-10 dB):55 Hz – 20 kHz
  • Frequency response (±3 dB):70 Hz – 20 kHz
  • Sensitivity (2.83 V/1 m):96 dB (half-space)
  • Maximum calculated SPL (1 m):122 dB (peaks 128 dB)
  • Permissible power (AES 2 h / 100 h):400 W / 250 W
  • Nominal impedance:8 Ω
  • Minimum impedance:5.7 Ω @ 160 Hz
  • Crossover Frequency / Topology:1.8 kHz; HF 3rd order (18 dB/oct) + conjugate; LF 2nd order (12 dB/oct)
  • LF Transducer:1 × 300 mm (12") with Kevlar reinforced cone, 75 mm coil
  • HF Transducer:1 × 25 mm (1") (25 mm diaphragm and coil), high-temperature polymer, patented design, fluid cooling
  • HF Protection:SonicGuard™ Low-Audibility
  • Directivity factor (Q):10.1 (1–16 kHz)
  • Directivity Index (DI):9.5 dB (1–16 kHz)
  • Construction of the enclosure:ABS with fiberglass, strongly braced
  • Rack:Zinc-rich coated steel (anti-corrosion)
  • Input connection:CE-covered terminal block; accepts cable up to 2.5 mm² or spade terminals (#6/#8/#10)
  • Fixing points:2 × M10 for U-bracket; M6 point for safety
  • Included accessories:Steel U-bracket
  • Bracket rotation range:±90°
  • Color:Black
  • Dimensions (H × W × D):402 × 402 × 445 mm
  • Depth with bracket included:542 mm
  • Net weight:14.0 kg (16.8 kg with stand)
  • Shipping weight:19.5 kg
