Electro-Voice ETX-12P - 12" (2-way) Active PA Speaker with FIR-Drive DSP, 2,000 W, and 90° × 60° Coverage

Electro-Voice ETX-12P - 12" (2-Way) Active PA Speaker with FIR-Drive DSP, 2,000 W, 90° × 60° Coverage

The Electro-Voice ETX-12P is a 2-way full-range system designed for professional live sound, rental and installation applications. It combines a 12" SMX2120 woofer with a 1.25" DH3-B compression driver and a 2,000 W Class D amplifier with FIR-Drive , achieving 135 dB SPL peak with constant directivity 90° × 60° . The tour-grade enclosure, made of 18 mm birch ply (13 layers), with EVCoat finish and 16 AWG steel grille, offers high durability, 8 M10 mounting points for flying and a dual-angle (0° / 7.5°) pole socket to optimize coverage on a tripod or sub.

Its LCD DSP interface with a single encoder simplifies tuning with presets by function ( Music/Live/Speech ) and location ( Tripod/Monitor/Wall/Suspend ), a 3-band parametric Room EQ , a delay with extended range in fine steps, a selectable high-pass filter for use with subwoofers (generic options and pairings with ETX-15SP/ETX-18SP) and polarity control . With a response (−3 dB) of 55–20,000 Hz and a range (−10 dB) of 43–20,000 Hz , the ETX-12P offers punch, vocal articulation and high intelligibility in a portable form factor.

Main features

• Transducers: LF 12" SMX2120 + HF 1.25" DH3-B (titanium diaphragm).
• Amplification and SPL: 2,000 W Class D with 135 dB SPL peak .
• Coverage: 90° (H) × 60° (V) pattern stable by SST waveguide.
• Frequency response: (−3 dB) 55 Hz – 20 kHz ; (−10 dB) 43 Hz – 20 kHz .
• Internal crossover frequency: 1,600 Hz .
• DSP with LCD: Music/Live/Speech presets, Tripod/Monitor/Wall/Suspend , 3-band Room EQ , HPF for use with sub, polarity and granular delay .
• Connectivity: 2 × XLR/TRS combo inputs with level control + 1 × XLR link/mix output.
• Mounting and rigging: 35mm socket with 0°/7.5° and 8 M10 points for suspension.
• Construction: 18mm birch ply with EVCoat and 16 AWG braid ; integrated carrying handles.
• Dimensions and weight: 613 × 381 × 400 mm (H × W × D); 23.6 kg .

Product benefits

• Uniform and controlled coverage (90° × 60°) that reduces lateral reflections and improves clarity.
• Quick Deployment : Built-in presets, HPF , and delay simplify adding with subwoofers and time alignment.
• Professional reliability : 18 mm birch enclosure, robust fittings and DSP protection with FIR-Drive.
• Versatility for use on a tripod, stacked on a sub, flown with an M10, or as a floor monitor.

Use cases

• Main PA for concerts, mobile DJ, corporate events and rentals.
• Fixed installation in halls, auditoriums and churches with controlled coverage needs.
• Sub-stacked systems with dedicated HPF and ETX-15SP/ETX-18SP presets for coherent summing.

Frequently Asked Questions

• Does it have a crossover for use with a subwoofer? Yes. The Subwoofer menu offers HPF at 80/100/120/150 Hz and pairings with the ETX-15SP / ETX-18SP .
• Does the socket allow the case to be tilted? Yes, the 35mm socket has two positions: 0° and 7.5° .
• What delay can I apply from the DSP? Up to 343 m in 0.25 m increments (also selectable in feet).

Description for projects

Electro-Voice ETX-12P active loudspeaker, 2-way; LF 12" SMX2120 , HF 1.25" DH3-B ; 2,000 W Class D; 135 dB SPL peak; 90° × 60° coverage; 55 Hz–20 kHz (−3 dB) / 43 Hz–20 kHz (−10 dB) response; 1,600 Hz crossover; DSP with 3-band Room EQ , HPF 80/100/120/150 Hz and ETX-15SP/ETX-18SP presets, polarity , delay up to 343 m; I/O: 2× XLR/TRS + 1× XLR link/mix ; 18 mm birch enclosure with EVCoat , 16 AWG grille; 35 mm socket (0°/7.5°) and 8× M10 ; dimensions 613 × 381 × 400 mm ; weight 23.6 kg .
