CROWN CDi 4|1200BL - Analog input amplifier + Blu Link, 4 channels, 1200W per output channel

CROWN CDi 4|1200BL – Analog input amplifier + BLU Link™, 4 channels, 1,200 W per channel

The CROWN CDi 4|1200BL is a high-power installation amplifier designed for large-scale environments (cinemas, houses of worship, hotels, cruise ships, auditoriums). It delivers 1,200 W continuous per channel into 4 Ω and can drive loads up to 100 Vrms without an external transformer. It features exclusive DriveCore™ technology for over 90% efficiency, a powerful DSP with pre-configured JBL presets, and HARMAN's BLU Link™ digital bus, which allows up to 256 channels of audio to be sent and received at low latency over Cat5e cable. A front-facing interface with LCD display and dedicated buttons, along with HiQnet™ TCP/IP remote monitoring and control, make setup and parameter adjustment (input router, delays, parametric EQs, crossover, LevelMAX™ limiters) quick and easy. The universal power supply with active PFC and variable speed forced cooling ensures reliable and quiet operation in critical applications.

Main features

• Power Rating: 1200 W per channel @ 4 Ω; 2400 W bridged mono @ 4 Ω
• Supported impedances: 2 Ω, 4 Ω, 8 Ω, 16 Ω; 70Vrms; 100 Vrms
• Inputs: 4 × Phoenix balanced (analog)
• BLU Link™: 2 × RJ45 for up to 256 channels of digital audio with low latency
• Integrated DSP: input router; input delay (0–1000 ms); crossover; 8-band parametric equalizers (I/O); output delay (0–100 ms); LevelMAX™ limiters
• Control and monitoring: HiQnet™ over TCP/IP; presets and diagnostics via Audio Architect software
• Front interface: graphic LCD display and dedicated buttons for on-site adjustment
• Power supply: 100–240 VAC, 50/60 Hz with active PFC
• Cooling: Variable speed front-to-back forced ventilation
• Rack format: 2 U (483 × 89 × 356 mm); weight 9.12kg

Product benefits

• Power and density: 4 channels of 1,200 W in just 2 U of rack space free up space for more equipment.
• Quick setup: JBL presets and BLU Link™ make setup quick without any transformers.
• Centralized control: remote monitoring and adjustment from HiQnet™ and Audio Architect.
• Custom tuning: Full DSP to optimize response and dynamics in each room.
• Efficiency and reliability: DriveCore™ and active PFC minimize consumption and heat, and variable cooling reduces noise.

Use cases

• Sound reinforcement for large cinemas and auditoriums with multiple zones and limited racks.
• Public address and voice evacuation systems in hotels, airports, and leisure venues.
• AV installations in temples, convention centers and cruise ships with network control.

Frequently Asked Questions

• Do you need transformers for 100 V? No; it delivers high native voltage without external transformers.
• How do I adjust the DSP presets? From the front display or via HiQnet™ Audio Architect.
• What is the latency of BLU Link™? Less than 1 ms, ideal for precise synchronization on long runs.

Description for projects

2U rack amplifier, 4 × 1200 W @ 4 Ω (2 Ω–16 Ω and 70/100 V native), BLU Link™, DSP with EQ, delay and limiters, HiQnet™ TCP/IP, active PFC, forced cooling, 483×89×356 mm, 9.12 kg.
