BSS

BSS BLU-806 - Signal processor with Dante and Blu Link

Only 2 left
SKU: BLU-806 EAN13: 691991033445
(0)
7.320,79 € inc. VAT

If you have any questions about this product, we can assist you by filling out the contact form

Ask an expert

Chat Email +34 621046470
Formerly known as BLU-806Features? Four I/O card slots? Configurable Inputs/Outputs? Analog Inputs (with Phantom Power per channel)? Analog Outputs? Digital Inputs (AES/EBU and S/PDIF)? Digital Outputs (AES/EBU and S/PDIF)? AEC Inputs (with Phantom Power per channel)? Hybrid Phone Card? Configurable Signal Processing? Rich palette of logic and processing objects? AES67 and Dante Audio with Dante Domain Manager support? 256-channel, low-latency, fault-tolerant digital audio bus? Clear front-panel LED indication? Informative front-panel display? Two-way paging functionality? 12 control inputs and 6 logic outputs for GPIO integration? Soundweb London Interface Kit for third-party control system integration (documentation)? HiQnet Device? Configuration, Control, and Monitoring from within HiQnet Audio Architect? AES67 Compatible? Complies with EN 54-16 for life safety applications
  • Brand:BSS Audio
  • Model:BLU-806 (BLU-806DA)
  • Guy:Network signal processor with BLU link and Dante™/AES67
  • Architecture:Open, configurable in HiQnet Audio Architect (drag and drop)
  • Card slots:4 (4 channels per card; maximum 16 inputs/outputs per chassis)
  • Compatible cards:Analog inputs (48 V phantom power per channel, gain 0–48 dB in 6 dB steps), Analog outputs, AES/EBU–S/PDIF digital inputs, AES/EBU–S/PDIF digital outputs, AEC inputs, Hybrid phone card
  • Dante™/AES67:64x64 channels; Primary and Secondary ports; Dante Domain Manager support
  • Control port:Dedicated Ethernet (separate from Dante)
  • Digital bus:BLU Link, 256 channels; Cat5e up to 100 m between devices; expandable to >40 km with fiber optic converters
  • Front indicators:LEDs per channel (Phantom, Sync, Signal, Clip) and informative LCD screen
  • Location:FunctionLocatebidirectional
  • GPIO:12 control inputs (GPI) and 6 logic outputs (GPO)
  • Serial communication:RS-232
  • Signal processing:800 MHz
  • Chassis:19”, 1U
  • Dimensions (H × W × D):45 × 483 × 318 mm
  • Weight:4.1 kg
  • Feeding:100–240 VAC, 50/60 Hz; consumption <55 VA; dissipation <188 BTU/h
  • Operating temperature:0–45 °C
  • Accordance:EN 54-16 (life safety applications)
  • Software:HiQnet Audio Architect / London Architect
  • Type Audio
  • Vendor BSS
  • SKU BLU-806
  • Bar-code 691991033445
