beamZ BC50-50F - Quick Release Tilt Claw (48–51 mm, M10, 100 kg) in Aluminum
The beamZ BC50-50F is a slimline, quick-release, tiltable clamp designed for mounting luminaires and accessories on 48–51 mm pipes and trusses with maximum agility. Its folding hinge allows the system to be folded/tilted for storage in a flight case or for adjusting the orientation during assembly. Made of high-strength aluminum , it combines low weight (0.35 kg) with a load capacity of 100 kg per piece . It features an M10 threaded bolt with a quick-release lock nut for fast attachment and detachment, even during frequent installations.
Main features
-
Foldable Quick Release Clamp for easy transport and fine adjustment.
-
Tube/truss range: 48–51 mm (standard Ø50 mm).
-
Quick fastening: M10 bolt with locking nut.
-
Construction: High-strength aluminum .
-
Maximum load per piece: 100 kg .
-
Key dimensions: D1 135mm; D2 48–51mm; D3 10mm; D4 85mm; Width (W) 30mm.
-
Weight: 0.35 kg.
Product benefits
-
Faster assembly and disassembly thanks to the quick release system.
-
Optimized logistics : the tiltable/foldable design makes it easy to store the light effect inside the flight case without disassembling the hardware.
-
Professional safety : high load capacity with robust aluminum body.
-
Careful aesthetics : discreet black finish for stages and television.
Use cases
-
Lighting rigging for events, festivals and theaters.
-
Rental and technical production : intensive rotation with frequent position changes.
-
Temporary installations : quick assembly of PAR spotlights, LED bars and accessories within the load limit.
Frequently Asked Questions
-
What pipe diameter does it fit? For 48–51 mm (includes the 50 mm standard).
-
What thread does it use? M10 .
-
What is the maximum load? 100 kg per claw (always respect the loads of the structure and the assembly).
-
Can I tilt the light fixture without disassembling it? Yes, the hinge makes it easy to fold/tilt the entire assembly during assembly and transport.
Good installation practices
- Use approved safety cables as a secondary retainer on each light fixture.
- Verify that the truss/tube and structure support the load with the required safety margin.
- Periodically check screws, bearing surfaces and the condition of the coupling.
Project description
beamZ BC50-50F quick-release tilting clamp in aluminum . For 48–51 mm tubing/truss . M10 bolt with locking nut. Max. load 100 kg. Dimensions: D1 135 mm; D2 48–51 mm; D3 10 mm; D4 85 mm; W 30 mm. Weight 0.35 kg.
