Audibax 1202 FFX - 12-channel analog mixing console with USB interface and effects processor

Audibax 1202 FFX - 12-channel analog mixing console with USB interface and effects processor

The Audibax 1202 FFX is a 12-channel analog mixing console that integrates an effects processor with 16 programs and a USB audio interface (master input/output) for direct recording and playback from a computer. It features six XLR mic/line inputs with 48V phantom power , two stereo channels via 6.3mm jacks , a 3-band EQ , panning, and balanced XLR and jack master outputs . It also includes a control room output , an auxiliary output , RCA 2-track input/output , a headphone output with independent level control , and a footswitch jack for switching effects. Its compact black chassis measures 315 × 100 × 340 mm (width × height × depth) and weighs 4.35 kg , making it ideal for home studios, live performances, and installation environments.

Main features

• 12 channels with pan control and 3-band EQ.
• Integrated effects processor with 16 selectable programs .
• USB interface for master input/output (recording and playback with computer).
• 6 XLR microphone/line inputs with 48V phantom power .
• 2 stereo inputs via 6.3 mm jack .
• Master outputs via XLR and 6.3 mm jack (balanced).
• Control Room and headphone output with independent adjustment.
• RCA 2-Track (input/output) for additional sources or recording.
• Auxiliary output for monitors or external sends.
• Footswitch socket for turning effects on/off.
• Dimensions : 315 × 100 × 340 mm; weight : 4.35 kg; color : black.

Product benefits

• Integrated workflow : mixing, effects and USB in a single console, reducing additional hardware.
• Flexible connectivity : XLR/line inputs, stereo jack and 2-Track to cover everything from microphones to players.
• Controlled sound : 3-band EQ per channel for quick adjustment of vocals and instruments.
• Professional operation : balanced master outputs, control room and headsets with independent level.
• Versatility : suitable for home studios , DJs, venues, events and rental companies.

Use cases

• Recording and streaming : USB connection to the computer to record the master or play backing tracks.
• Live sound reinforcement : 6 preamps with phantom power for bands, conferences and worship.
• Fixed installation : bars, classrooms or gyms with zone control via auxiliary and control room.
• DJ and events : easy integration of multiple sources and internal effects without external processors.

Frequently Asked Questions

• What functions does the USB connection offer? It allows you to send the master signal to the computer and return audio from the computer to the mixer.
• Is the phantom power 48V? Yes, the console supplies 48V phantom power for condenser microphones.
• Can the effects be controlled with a pedal? Yes, the footswitch jack allows you to switch the effects on/off.
• What are the main outputs? Balanced XLR and 6.3 mm jack master outputs, plus Control Room and headphone outputs .

Usage recommendations

• Activate the 48V phantom power only when all microphones are connected and never with unbalanced XLR cables.
• Use the auxiliary to generate an independent monitor mix without affecting the master.
• Adjust the gain of each channel to optimize the signal-to-noise ratio before equalizing.

Project description

12-channel analog mixing console with USB interface (master I/O) and 16-program effects processor; 6 XLR mic/line inputs with 48V phantom power; 2 stereo inputs via 6.3mm jack; 3-band EQ and pan per channel; XLR and 6.3mm jack master outputs; control room output; 1 auxiliary send; 2-track RCA I/O; headphone output with independent level control; footswitch jack for effects; dimensions 315 × 100 × 340 mm; weight 4.35 kg; color black.
