Audibax Elipse 5 - Pair of 5" 2-way wall-mounted speakers (white, 8 Ω, 40 W RMS) with steel grille

Audibax Elipse 5 - Pair of 5" 2-way wall-mounted speakers (white, 8 Ω, 40 W RMS) with steel grille

The Audibax Elipse 5 are a pair of passive, wall-mounted speakers that combine a compact size, discreet design, and clear sound for background music and speech. Each speaker features a 135 mm (5") woofer and a 13 mm tweeter in a 2-way configuration, operating at 8 Ω with an RMS power of 40 W per speaker , a sensitivity of 88 dB (1W/1m) , and a frequency response of 75 Hz to 18 kHz . Supplied as a pair , they include wall brackets for quick and secure installation. Their ABS frame/housing and steel grille provide durability, while the white finish blends seamlessly into hotels, restaurants, classrooms, offices, and retail spaces.

Main features

• Installation format: passive wall speakers, supplied in pairs.
• Transducers: 135 mm (5") woofer + 13 mm tweeter, 2-way system.
• Acoustic performance: 75 Hz – 18 kHz, sensitivity 88 dB (1W/1m).
• Power and load: low impedance 8 Ω, 40 W RMS per speaker.
• Construction: ABS casing with metal mesh for protection and clean aesthetics.
• Easy assembly: Includes wall brackets for quick installation.
• Compact dimensions: 18 × 25 × 16 cm; weight: 2.6 kg (pair).
• Indoor use: IP20 rating for dry locations.

Product benefits

• Clear sound with good intelligibility for announcements and background music in small and medium-sized spaces.
• Installation and adjustment are hassle-free thanks to the included wall mount and its compact size.
• Aesthetic integration into light ceilings and walls: understated design and white-painted steel grid.
• Wide compatibility with Low-Z (8 Ω) installation amplifiers.
• Ideal performance/price ratio for projects with multiple sound points.

Use cases

• Horeca: restaurants, cafes, bars, hotels and lobbies.
• Retail and showrooms with background music and advertisements.
• Education and offices: classrooms, meeting rooms, offices and common areas.
• Gyms, clinics and customer service centers (interior).

Frequently Asked Questions

• Do they come with two speakers? Yes, the Elipse 5 is supplied in pairs.
• Does it include brackets? Yes, wall brackets for installation are included.
• Do they need an amplifier? Yes. They are 8 Ω passive speakers; you require a Low-Z installation amplifier that delivers safe power for 8 Ω.
• Are they suitable for 70/100 V lines? No. This model operates at low impedance (8 Ω). For 70/100 V, versions with a transformer are required.
• Can I adjust them? The wall mount allows you to adjust the angle to better cover the listening area.

Installation tips

• Height and orientation: Place the speakers at ≥2 m high and point them towards the listening area for even coverage.
• Power selection: size the amplifier with a reasonable margin over 40 W RMS per channel, avoiding peak saturation.
• Wiring: Use cable of appropriate cross-section for the distance (e.g., 2×1.5 mm² up to ~20 m) and respect the polarity.

Project description

Pair of passive wall-mounted speakers, 2-way (135 mm woofer + 13 mm tweeter), 8 Ω, 40 W RMS per speaker, sensitivity 88 dB (1W/1m), frequency response 75 Hz–18 kHz, ABS housing with steel grille, white, dimensions 18 × 25 × 16 cm, weight 2.6 kg, IP20 rating. Supplied as a pair (2 units) with wall brackets.
