Audibax Elipse 4 - Pair of 4” 2-way wall-mounted speakers (white) for indoor installation

Audibax Elipse 4 - Pair of 4” 2-way wall-mounted speakers (white) for indoor installation

The Audibax Elipse 4 pair is a 2-way passive speaker system designed for wall mounting and intended for discreet and homogeneous sound reinforcement indoors. Each speaker incorporates a 4” woofer (1” voice coil) and a 0.5” (13 mm) tweeter , offering a frequency response of 50 Hz to 20 kHz , sensitivity of 89 dB (1W/1m) , and a maximum SPL of 102 dB . They operate at low impedance (8 Ω) with 10 W RMS per unit (20 W peak) and feature 70/100 V line inputs with selectable power levels of 2.5/5/10 W RMS , facilitating integration into both low-Z amplification and distributed public address systems. Their ABS enclosure, metal grille , and included bracket ensure a firm and durable installation. Dimensions per speaker: 15 cm wide × 21.5 cm high × 13 cm deep ; weight 1.79 kg . Color: White .

Main features

• 2-way configuration : 4” woofer + 0.5” tweeter
• Wide response 50 Hz–20 kHz, sensitivity 89 dB (1W/1m) and max. SPL 102 dB.
• Dual working mode : 8 Ω (10 W RMS) or 70/100 V line (2.5/5/10 W RMS).
• 120° (V) × 120° (H) dispersion for uniform coverage.
• Construction : ABS enclosure and metal grille with white finish.
• Bracket-type wall mount included for stable mounting.
• Speaker terminal connection .
• Dimensions per unit : 15 × 21.5 × 13 cm; weight 1.79 kg.
• Use : indoors (commercial and residential installations).

Product benefits

• Versatile integration : valid for both Low-Z (8 Ω) and 70/100 V , simplifying new projects or expansions.
• Homogeneous coverage thanks to its 120° × 120° dispersion and 2-way design.
• Clean installation with included wall bracket and accessible connection terminal.
• Discreet aesthetics : white finish and metal mesh that blends in with the surroundings.
• Efficiency in ambient sound : good voice intelligibility and background music with low maintenance.

Use cases

• Hospitality and retail : restaurants, bars, cafes and shops with continuous background music.
• Education and offices : classrooms, meeting rooms, receptions and hallways.
• Leisure and wellness centers : gyms, spas and waiting areas.
• Housing : living rooms, kitchens and covered terraces (indoor use).

Frequently Asked Questions

• Are they sold in pairs? Yes, the product includes 1 pair of speakers with their wall mounts.
• Do they work on 100V/70V lines? Yes, they have 2.5/5/10W RMS outlets in addition to the 8Ω mode.
• What amplifier do I need? Any 8 Ω stage or mixer-amplifier (10 W RMS per speaker) or a 70/100 V line amplifier with power appropriate to the number of points.
• Do they include brackets? Yes, they include wall brackets for mounting.
• Are they for outdoor use? No, they are designed for indoor use .

Installation recommendations

• Distribute several units for even coverage and listening at moderate volume.
• At 100V/70V, select the socket (2.5/5/10W) based on the area and total power available.
• Respect polarity on the terminals and firmly fix the brackets to a solid wall.

Project description

Pair of passive indoor wall-mounted speakers; 2-way; 4” woofer (1” voice coil) + 0.5” tweeter; sensitivity 89 dB (1W/1m); max. SPL 102 dB; impedance 8 Ω; Low-Z power 10 W RMS (20 W peak); 70/100 V 2.5/5/10 W RMS inputs; dispersion 120° V × 120° H; ABS enclosure with metal grille; connection terminal; dimensions per unit 15 × 21.5 × 13 cm; weight per unit 1.79 kg; white color.
