OSRAM 64751 P2/12 - Linear halogen lamp 1,250 W 230 V R7s for cinema, TV and stage

OSRAM 64751 P2/12 - Linear halogen lamp 1,250 W 230 V R7s for cinema, TV and stage

The OSRAM 64751 P2/12 is a double-ended (R7s) studio halogen lamp designed for professional lighting in film, television, theater, and events . It offers a color temperature of 3200 K (studio tungsten), a CRI of 100 , and a luminous flux of 33,500 lm , with an efficacy of 27.6 lm/W . Its 200-hour rated life and continuous dimming capability make it a standard for cyc lights , softlights , and linear projectors. With a total length of 185.7 mm and a diameter of 12 mm , it integrates easily into compatible fixtures and supports a p15 burn-in position (horizontal ±15°) for stable performance.

Main features

• Power / voltage: 1,250 W / 230 V
• Base: R7s (double socket)
• Luminous flux: 33,500 lm
• Color temperature: 3,200 K (studio tungsten)
• Color Rendering Index (CRI): 100
• Luminous efficacy: 27.6 lm/W
• Nominal life: 200 h
• Dimensions: Ø 12 mm; length 185.7mm
• Burning position: p15 (horizontal ±15°)
• Dimmable: Yes (with natural tungsten amber shift )

Product benefits

• True color and skin tones: CRI 100 and constant 3,200 K for perfect blending with other tungsten sources.
• Stable output: virtually constant flow throughout its lifespan, ideal for scene continuity.
• Total control: smooth dimming for clean transitions and fine exposure effects.
• Easy integration: R7s linear format and 185.7 mm length widely compatible in studio and theater.

Use cases

• Film and TV: softlights and cyc lights as uniform fill on set.
• Theatre and concerts: lighting of curtains, cycloramas and large surfaces.
• Professional photography: tungsten setups with fine control of intensity and color.

Frequently Asked Questions

Is it dimmable? Yes, it is 100% dimmable with the characteristic amber shift of tungsten when dimming.

What is the working orientation? p15 , that is, horizontal operation with an approximate tolerance of ±15°.

How does it differ from a domestic R7s? This 1,250 W, 3,200 K P2/12 version is designed for professional use (higher luminous flux, CRI 100 and specific nominal life) and requires suitable luminaires and ventilation .

Installation and safety

• Always install in suitable studio halogen luminaires with thermal protection.
• Avoid touching the quartz with your fingers; use clean gloves or a lint-free cloth.
• Respect position p15 and ensure ventilation to maintain working temperature.

Project description

OSRAM 64751 P2/12 linear halogen lamp; R7s base; 1,250 W , 230 V ; 33,500 lm ; 3,200 K ; CRI 100 ; 27.6 lm/W ; 200 h life ; p15 ; dimensions Ø 12 mm × 185.7 mm ; dimmable.
