AFX Light WATERBAR - Water Movement Effect 120W - IP65

AFX Light WATERBAR – “Water Movement” Effect 120W IP65

The AFX Light WATERBAR is a professional outdoor luminaire that recreates dynamic, multi-colored waves of light, evoking flowing water and the magical dance of the Northern Lights. Powered by three 40W OSRAM 4-in-1 LEDs and a total power consumption of 120W, it projects a rippling effect on outdoor surfaces thanks to its 120° optics. Its IP65 aluminum housing ensures weather resistance and optimal heat dissipation. Equipped with 6-channel DMX512 control, RDM, and standalone modes (auto, manual, master-slave), it allows speed and dimmer adjustment to customize each scene. Thermal and surge protection ensure reliable operation and extend the life of the fixture.

Main features

• 3 OSRAM 4-in-1 40 W LEDs (RGBW) for multicolor shows.
• IP65 rating: resistant to rain, dust and outdoor environments.
• 120° projection angle for wide, immersive coverage.
• Total consumption of 120 W with passive cooling and aluminum housing.
• 6-channel DMX512 control and RDM function for remote management.
• Operating modes: DMX512, automatic (predefined programs), manual and master-slave.
• Effect speed adjustment and linear dimmer for smooth transitions (0–100%).
• Thermal protection: reduces power when exceeding 60 °C to protect the LEDs.
• Surge and power surge protection for added safety.
• Projection of “moving water” and simulation of the northern lights on walls and facades.

Product benefits

• Exterior visual impact: dynamic and enveloping effect ideal for facades, swimming pools and terraces.
• Guaranteed durability: IP65 and thermal management extend outdoor life.
• Control flexibility: DMX, RDM and standalone modes cover any operational requirement.
• Easy installation: mounting bracket included and professional PowerCON connections.
• Operational safety: built-in thermal and electrical protection.

Use cases

• Architectural lighting of facades, walls and waterfalls.
• Decorative effects in swimming pools and garden areas.
• Theming of terraces, hotels and outdoor spaces.
• Ambiences at outdoor events and fairs.
• Creating immersive environments in outdoor restaurants and lounges.

Frequently Asked Questions

• How do I program the speed of the effect? ​​Adjust the speed using the DMX console or manually using buttons.
• Is it compatible with other DMX equipment? Yes; it uses the standard DMX512 protocol and supports RDM for remote configuration.
• Does it require special maintenance? Clean the housing occasionally and check connections to maintain tightness.
• Can it work in coastal environments? Its IP65 rating allows for outdoor use, but frequent cleaning is recommended in highly saline environments.

Description for projects

120W IP65 outdoor luminaire with 3 x 40W OSRAM 4-in-1 LEDs, 120° projection, 6-channel DMX512, RDM, auto/manual/master-slave modes, 0–100% dimmer, speed adjustment, thermal and surge protection.
