XVive U45 - Wireless In-Ear Monitoring System

XVIVE U45 – Wireless In-Ear Monitoring System

The XVIVE U45 is a professional wireless in-ear system offering high-fidelity personal monitoring for musicians and sound technicians. It operates on the 5.8 GHz band with True Diversity technology, guaranteeing a stable, interference-free signal up to 30 m line-of-sight. Its uncompressed 24-bit/48 kHz digital transmission, 20 Hz to 20 kHz frequency response, and less than 5 ms latency deliver crystal-clear, synchronized live sound. Both the transmitter and receiver are compact, rechargeable, and lightweight, with a battery life of approximately 5 h and fast USB charging. The transmitter includes an Aux/Line switch and XLR to jack output, while the receiver features a 3.5 mm stereo output, suitable for any in-ear monitor.

Main features

• True Diversity 5.8GHz Wireless Technology: Six auto-scanning channels for uninterrupted connection.
• Uncompressed 24-bit/48kHz Audio: Studio-quality with 110dB dynamic range and 110dB signal-to-noise ratio.
• Full frequency response: 20 Hz–20 kHz for faithful reproduction of every nuance.
• Ultra-low latency: Less than 5ms, imperceptible in live performances.
• Range up to 30m: Obstacle-free, ideal for large venues.
• 5h autonomy: Rechargeable batteries with fast USB charging.
• Aux/Line switch: Input level adjustment on the transmitter for mixer or line signals.
• Outputs: Transmitter with male XLR to mono jack; receiver with 3.5 mm stereo jack.
• Robust ABS housing: Lightweight and durable (Tx 90 g, Rx 118 g).

Product benefits

• Precise wireless monitoring with professional audio quality.
• Signal stability in saturated environments thanks to True Diversity.
• Plug & play configuration that reduces assembly times.
• Portability and lightness, perfect for touring, rehearsals and broadcasting.
• Gain adjustment and Aux/Line formats that facilitate integration into any system.

Use cases

• Personal monitoring at concerts, tours, and festivals.
• Studio recordings without cable interference or background noise.
• Streaming productions and live events.
• Classes and formations with freedom of movement on stage.

Frequently Asked Questions

• How do you select the channel?
  Automatically scans the six available channels and connects to the one with the least interference.
• What is autonomy?
  Around 5 hours of continuous use after a full charge via USB.
• Can I use multiple systems together?
  Up to six units can operate simultaneously without interfering with each other.
• What type of headphones can I connect?
  Receiver with 3.5mm stereo jack compatible with most IEMs and headphones.

Description for projects

5.8 GHz True Diversity wireless system with U45T transmitter and U45R receiver; 24-bit/48 kHz audio; < 5 ms latency; 20 Hz–20 kHz response; 30 m range; 6 RF channels; Aux/Line switch; XLR to jack and 3.5 mm jack outputs; 5 h battery life; Tx weight 90 g, Rx 118 g; ABS material.
