GUIL ELC-700 - Top-loading telescopic lifting tower. Folding base.

Out of stock
SKU: ELC-700
(0)
263,04 € inc. VAT

Gastos de envío, si aplican, calculados al finalizar la compra.

Devolución en 14 días
Pago seguro y cifrado
3 años garantía*
Métodos de pago
  • Apple Pay
  • Google Pay
  • Maestro
  • Mastercard
  • MobilePay
  • Shop Pay
  • Visa

También aceptamos transferencia bancaria

If you have any questions about this product, we can assist you by filling out the contact form

Ask an expert

Chat Email +34 621046470

Maximum Height: 3.30 m / Maximum Load: 85 kg

Ref. ELC-700

Lightweight and compact mechanical lifting telescopic tower, specially designed to facilitate transportation once folded. The ELC-700 tower is certified for lifting loads of up to 85 kg to a maximum height of 3.30 meters and with a Ø35 mm terminal.

Folded Measurements:
 * 260 x 320 x 1700 mm (with winch crank)
 * 260 x 160 x 1700 mm (without winch crank)

SPECIFICATIONS ELC-700
Maximum height: 3.30m
Maximum load: 85kg
Security: ASB-3 System (Automatic Locking System)
Self-braking winch: 450kg
Folded Height: 1.70m
Material: Steel
In accordance with the Regulations: DGUV 17 & 18, DGUV Rule 115-002 (Former BGV-C1 )
DIN EN 17206 (Replaces DIN 56950-1 ), 2006/42/EC
Net weight: 13kg
Adapters: Ø 35mm


GUARANTEED SECURITY:

The ELC-700 elevator is provided with two safety systems ; guaranteeing maximum reliability during the process of lifting and lowering loads.

1. Self-braking winch (450 Kg) that stops the load at the desired height and prevents recoil.
2. ASB-3 system: Security lock with pin.

The ELC-700 tower is tested in accordance with European safety standards : DGUV Regulation 17 & 18, DGUV Rule 115-002, DIN 56950-1 and 2006/42/CE .

The construction of this elevator is carried out with the most advanced welding equipment that guarantees maximum safety and resistance, meeting at all times the requirements of solidity, maneuverability and lightness necessary for lifting loads.


BASE:

Compact base, composed of three stabilizing legs with a folding design, made of steel with a textured black paint finish (Epoxy) with double treatment for outdoor use.


LOAD LIFT:

The lifting of the load is carried out using a self-braking manual winch (450 Kg) that prevents recoil and stops the load at the desired height (when the crank is released, the winch locks the load in place, preventing recoil).


TRANSPORT:

Its small dimensions and light and compact design allow for comfortable and easy handling to your workplace, and can be transported in any car.

A single technician can transport and manipulate an ELC-700 lift effortlessly, saving time and increasing productivity.
