AFX Light SPOT60LED - 60W LED SPOT Moving Head
The AFX Light SPOT60LED is a powerful SPOT moving head equipped with a high-luminosity 60W white LED that delivers a bright, crisp beam. It incorporates 14 DMX channels for detailed control, a 6-interchangeable rotating gobo wheel , an 8-fixed metal gobo wheel , and a 7-color + white rainbow gobo wheel. Its rotating triangular prism and gobo shake function add dynamism to lighting designs, while the DMX motorized focus and strobe of up to 20 flashes/s maximize the creativity of every show.
With Pan 540°/360°/180° and Tilt 270°/180°/90° movement, adjustable beam angle between 17° and 25° and a brightness level of 24,500 Lux @ maximum , this moving head guarantees a professional performance in discos, theaters and corporate events. Its LCD screen allows quick setup in Automatic, Sound, DMX or Master-Slave mode, adapting to both experienced operators and stand-alone installations.
Main features
-
Light source: 1× 60W high brightness white LED
-
DMX Channels: 14
-
Rotating gobos: 6 interchangeable
-
Fixed gobos: 8 metallic
-
Colors: 7 + white with rainbow effect
-
Prism: Rotating triangular
-
Function: Gobo shake
-
Focus: Motorized, DMX controllable
-
Strobe: Up to 20 flashes/s
-
Movement: Pan 540°/360°/180°, Tilt 270°/180°/90°
-
Beam angle: 17°–25°
-
Brightness: 24,500 Lux @ maximum
-
Screen: LCD
-
Operating modes: Automatic, Sound, DMX, Master-Slave
-
Weight: 6.5 kg
Product benefits
-
High optical precision: The prism and gobo wheels allow you to create complex and defined effects.
-
Control versatility: Fine-tune via DMX or standalone modes for DJs and quick setups.
-
Robustness and reliability: Solid construction for intensive use on tours and in clubs.
-
Flexible mounting: Compatible with floor stands or truss rigging.
-
Quick start-up: Intuitive LCD display and presets in automatic mode.
Use cases
- Club and discotheque atmospheres synchronized to the rhythm of the music.
- Spot lighting on concert and theater stages.
- Corporate events with smooth transitions between scenes.
- Traveling shows where quick set-up is key.
Frequently Asked Questions
-
Can I use it without a DMX console? Yes; it has Automatic and Sound modes for standalone operation.
-
How do I select from six rotating gobos? You can change the gobo at any time using the LCD menu.
-
What is the full range of motion? Pan: 540°/360°/180°, Tilt: 270°/180°/90°.
-
Is it easy to transport? Its 6.5 kg weight and compact casing make it easy to transport and set up.
Description for projects
SPOT moving head with 1× 60 W white LED, 14 DMX channels, static and rotating gobo wheels, color wheel, rotating triangular prism, DMX controllable focus and strobe, Pan 540°/360°/180°, Tilt 270°/180°/90°, beam angle 17°–25°, brightness 24,500 Lux, LCD display, Auto/Sound/DMX/Master-Slave modes, weight 6.5 kg.
