Skytec SPL1000EQ - 2x500W Stereo Amplifier with 3-Band EQ for DJ and Installation (19", 2U)

Skytec SPL1000EQ - 2x500W Stereo Amplifier with 3-Band EQ for DJ and Installation (19", 2U)

The Skytec SPL1000EQ is a 2x500W (at 4Ω) stereo power amplifier with 3-band EQ , designed for DJ booths, venues and small installations. It features multiple rear stereo RCA inputs for TVs, CD/DVD players, tuners or mixers, and a front 3.5mm mini-jack input for portable sources. The input selector , clip indicator and blue LED lighting on the front make it easy to operate even in low-light environments. It offers a 20Hz–20kHz bandwidth , THD <0.05% , a >95dB signal-to-noise ratio and >82dB crosstalk for reliable performance with 4–8Ω speakers. 19” (2U) rack mount, 482x270x88mm dimensions , and weighs 5.3kg .

Main features

• 2×500 W (4 Ω) / 2×350 W (8 Ω) max. power per channel: enough headroom for compact PA and DJ systems.
• 3-band equalizer on the front to adjust bass, midrange and treble without an external mixer.
• Inputs : 3× rear stereo RCA + front 3.5mm mini-jack ; dedicated input selector .
• Speaker outputs via screw terminals for bare wire.
• Indicators : signal and clip/peak per channel; front panel with blue status LEDs .
• Audio specifications : 20 Hz–20 kHz, THD <0.05 % , S/N >95 dB , crosstalk >82 dB .
• Line sensitivity 0.775–1.2 V; input impedance 10 kΩ.
• 19” rack format (2U), 482 × 270 × 88 mm , 5.3 kg ; power supply 220–240 VAC 50 Hz .

Product benefits

• Easy installation : quick switching between sources thanks to the input selector and the front auxiliary input.
• Instant sound control without adding external processors thanks to the built-in 3-band EQ.
• Safe operation : Clip- on LEDs help prevent clipping and protect speakers.
• Professional 19” (2U) format for rack or flight case in mobile and fixed cabins.

Use cases

• DJ booths in pubs, bars and small venues.
• Basic sound reinforcement installations in classrooms, gymnasiums, social centers, or multipurpose spaces.
• Mobile events with 19” flightcase mounting.

Compatibility and connections

Works with 4–8 Ω loads (min. 4 Ω). Connect RCA or 3.5 mm sources and speakers to the screw terminals . Adjust levels to prevent the clip indicator from lighting up. For passive speakers, use a cable of appropriate cross-section (e.g., 2x2.5 mm² in medium runs).

Frequently Asked Questions

• Does it include Bluetooth, USB, or MP3 playback? No. This SPL1000EQ model includes a 3-band equalizer and analog inputs; the MP3/BT versions are available in other models in the series.
• Can I use it with two pairs of speakers? Yes, as long as the resulting impedance per channel doesn't drop below 4 Ω and the speaker power ratings are met.
• What type of speaker output does it use? Screw terminals for bare wire (no Speakon connectors).

Description for projects

Stereo amplifier with 3-band EQ; max. power 2×500 W @ 4 Ω ( 2×350 W @ 8 Ω ); response 20 Hz–20 kHz ; THD <0.05 % ; S/N >95 dB ; crosstalk >82 dB ; inputs 3×RCA + 1×3.5 mm front; terminal outputs ; line sensitivity 0.775–1.2 V ; input impedance 10 kΩ ; power supply 220–240 VAC 50 Hz ; rack format 19” (2U) ; dimensions 482 × 270 × 88 mm ; weight 5.3 kg ; black color.
