Ibiza Light & Sound SCAN500RGB - 500mW RGB Animation Laser with DMX

Ibiza Light & Sound SCAN500RGB - 500 mW DMX RGB Animation Laser

The Ibiza Light & Sound SCAN500RGB is an advanced 500mW RGB animation laser designed to produce spectacular tunnel, ceiling, spiral, and dynamic shape effects. Equipped with high-speed 25kpps scanning motors, it supports DMX control on 5 or 34 channels, as well as automatic, master-slave, sound, and remote modes. It comes with a security key and remote control to ensure versatile and safe use in clubs, mobile discos, theaters, and live events.

Main features

• 5 or 34 DMX channels for detailed pattern and motion control
• High-speed 25 kpps scanners ensure smooth, sharp scans
• Operating modes: DMX, Auto, Master-Slave, Sound and IR Remote
• Pre-recorded animation effects: tunnel, ceiling, spiral, geometric shapes and more
• Total power 500 mW (Red 200 mW @ 638 nm, Green 100 mW @ 532 nm, Blue 200 mW @ 445 nm)
• Laser class 3B with integrated safety key
• Power supply: AC 100–240 V, 50/60 Hz; consumption 30 W; slow-blow fuse 250 V 2 A
• Dimensions: 246 × 211 × 105 mm; weight: 3.5 kg

Product benefits

• Striking light coverage with moving patterns that fill the space
• Control flexibility for all types of installations, from small events to large productions
• Quick plug & play start-up and instant mode switching with the IR remote
• High-speed scanners that avoid distortions and blurred shadows
• Robust and secure design, with security key to prevent unauthorized use

Use cases

• DJ shows and mobile discos
• Concerts, festivals and live tours
• Theaters, auditoriums and stage productions
• Corporate events, trade shows and product presentations
• Art installations, mapping and immersive experiences
• Setting up themed clubs, bars and lounges

Frequently Asked Questions

• What maintenance does the laser require? Occasional lens cleaning and fuse checking; scanners do not require adjustment.
• Can I daisy-chain multiple SCAN500RGBs? Yes, in master-slave mode, they synchronize multiple units simultaneously.
• What is the effective range of the IR remote? Approximately 5 m line of sight.
• Is it compatible with standard DMX consoles? Yes, it supports 5 or 34 DMX channels depending on the complexity of the show.

Description for projects

500mW RGB animation laser (200mW Red @ 638nm, 100mW Green @ 532nm, 200mW Blue @ 445nm), 25kpps scanners, 5/34 DMX channels, Auto/Master-Slave/Sound/IR modes, AC 100–240V, 30W, class 3B, includes safety key and IR remote; dimensions 246×211×105mm, weight 3.5kg.
