Ibiza Light & Sound SCAN1100RGB - 1100 mW RGB multipoint laser with DMX/ILDA/IRC

Ibiza Light & Sound SCAN1100RGB – 1100 mW RGB multipoint laser with DMX/ILDA/IRC

The SCAN1100RGB is a Class 3B RGB animation laser that combines red (300 mW @ 638 nm), green (200 mW @ 532 nm) and blue (600 mW @ 445 nm) diodes to deliver 1100 mW of total power. Thanks to its high-speed scanners (25 kpps), ILDA input/output (DB25 + RJ45) and DMX control (5 or 34 channels), plus auto, master-slave, sound-active and IRC modes, it allows you to generate tunnels, ceilings and a multitude of pre-programmed shapes with extreme fluidity. It comes with a security key and remote control, and its compact chassis (246 × 211 × 105 mm), 3.5 kg, allows it to easily integrate into any professional club or event setup.

Main features

• Laser power: 1100 mW total (Red 300 mW/638 nm + Green 200 mW/532 nm + Blue 600 mW/445 nm).
• Scanners: High performance, 25 kpps for fast and precise movements.
• ILDA control: DB25 + RJ45 input and output for integration into complex systems.
• DMX: 5 or 34 selectable channels to customize every beam parameter.
• Operating modes: DMX, automatic, master-slave, sound-active and IRC control.
• Pre-programmed effects: animations, tunnels, ceilings and more than 40 fixed and dynamic patterns.
• Safety: Interlock key to prevent accidental opening.
• Power supply: AC 100–240 V, 50/60 Hz; consumption 30 W; 250 V 2 A slow-blow fuse.
• Dimensions: 246 × 211 × 105 mm; weight: 3.5 kg.
• Working temperature: 10 °C to 40 °C.

Product benefits

• Extreme visual impact: intense RGB beams and ultra-fast scans to cover large surfaces.
• Maximum versatility: full control via DMX, ILDA or remote, with standalone and beat-synced modes.
• Professional integration: ILDA and DMX at 5/34 channels allow for custom shows synchronized with other lasers.
• Certified Safety: Class 3B with safety key and internal fuse for reliable use.
• Compact installation: lightweight design and small footprint for club or stage rigging.

Use cases

• Disco and nightclub shows.
• Concerts and DJ tours that require synchronized laser effects.
• Corporate events and presentations seeking visual impact.
• Integration into large-format light shows with ILDA/DMX control.

Frequently Asked Questions

• How many pre-programmed patterns does it have? It includes over 40 stationary and dynamic designs, such as tunnels and roofs.
• How do I activate ILDA mode? Connect a DB25 or RJ45 cable to the ILDA input and use external software to send signals.
• Can master-slave linking be used? Yes, multiple SCAN1100RGBs can be synchronized without an additional controller.
• Is the fan noisy? The internal cooling system is quiet, suitable for living rooms and theaters.

Description for projects

RGB laser 1100 mW (300 mW R + 200 mW G + 600 mW B), scanner 25 kpps, ILDA DB25/RJ45, DMX 5/34 ch, auto/sound/master-slave/IRC modes, fuse 250 V 2 A, AC 100–240 V, consumption 30 W, dims 246×211×105 mm, weight 3.5 kg.
