Electro-Voice RE97LTx Beige - Subminiature Omnidirectional Lavalier Microphone with TA4F Connector

Electro-Voice RE97LTx Beige - Subminiature Omnidirectional Lavalier Microphone with TA4F Connector

The Electro-Voice RE97LTx BEIGE is a subminiature lavalier microphone designed for clear, natural voice capture in professional spoken-word applications. Its back-electret condenser capsule with an omnidirectional polar pattern delivers a consistent response even when the speaker moves, maintaining intelligibility and a balanced timbre. Thanks to its ultra-discreet form factor—a capsule only 3 mm in diameter and 7 mm in length—and beige finish, it blends easily into clothing and skin to blend seamlessly into theater, broadcast, and corporate events.

It features a 1.22 m shielded cable with a Switchcraft TA4F connector , directly compatible with Electro-Voice and Telex bodypack transmitters and adaptable to other systems with appropriate wiring. It includes a double clothing clip and two windscreens (long and short) to reduce wind and breath noise. Alternatively, it can be used with the optional TXA to XLR adapter for wired applications with phantom power.

Main features

• Subminiature and discreet format : 3 mm × 7 mm capsule in beige color for minimal visual impact on camera and stage.
• Omnidirectional pickup : uniform sound without the “comb effect” when moving your head; ideal for spoken word.
• Clean, natural audio : 50 Hz to 15 kHz frequency response, −48 dBV (4 mV/Pa) sensitivity, and 88 dB dynamic range.
• Wireless ready : TA4F connector (EV/Telex); typical +5 V DC power supply from beltpack.
• Included accessories : double clip, short and long windscreen, and carrying bag.
• Robust construction : ultra-flexible 1.22m and 1.30mm diameter shielded cable.

User benefits

• Maximum discretion on stage : the ultra-small size and beige color make it easy to hide in costumes and makeup.
• Level consistency : omni pattern that maintains clarity even when the position relative to the soundhole changes.
• Instant integration : direct connection to EV/Telex beltpacks with TA4F; optional XLR adapter.
• Less unwanted noise : windscreen and double clip to control wind and cable friction.
• Lightweight : only 10.5g, comfortable for long time wearing.

Use cases

• Theatrical and musical performances where actors need to be miked invisibly.
• Corporate AV presentations and conferences with freedom of movement.
• Places of worship and live events with priority given to speech intelligibility.
• Broadcast, streaming, and content creation with close-up shots and clean aesthetics.

Frequently Asked Questions

• Is the RE97LTx a condenser microphone? Yes, it uses a back-electret condenser capsule and requires bias (+5 V DC) provided by the bodypack.
• Can it be used with an XLR cable? Yes, with the optional TXA to XLR adapter with phantom power.
• Does it include a wireless transmitter? No. The microphone comes with a TA4F cable and accessories.
• Can it be used for systems other than EV/Telex? This is possible with appropriate cabling/adapters; refer to the pinout diagram from the beltpack manufacturer.

Description for projects

Subminiature back-electret condenser lavalier microphone, omnidirectional pattern, 50 Hz–15 kHz response, −48 dBV (4 mV/Pa) sensitivity, >120 dB max SPL, 32 dBA equivalent noise, 88 dB dynamic range, 3 kΩ output impedance, +5 V DC power (from bodypack), 310 µA current consumption. Capsule 3 mm (Ø) × 7 mm (long). Shielded cable 1.22 m × 1.30 mm (Ø) with Switchcraft TA4F connector. Microphone weight 10.5 g. Beige. Accessories: double clip, short and long windscreens, pouch; optional accessory: TXA to XLR adapter.
