SHEHDS LA12WRGB - 12W 25kpps ILDA RGB Laser Projector

SHEHDS LA12WRGB - 12W 25kpps ILDA RGB Laser Projector

The SHEHDS LA12WRGB 12W laser projector with 25 kpps scanning delivers a professional visual experience for large-format events and shows. Its high-power RGB system generates a wide color palette (red, green, blue, yellow, purple, cyan, and white) and enables mixing of pure and blended tones with projection uniformity exceeding 98%. With a beam divergence of less than 1.2 mrad and a 5.5 mm exit window, it projects sharp designs up to 200 m away (optimal between 30 and 100 m).

Equipped with high-flow fan-forced cooling and overcurrent and overvoltage protection, it maintains consistent performance indoors (working temperature from 15°C to 45°C). Its robust chassis and IP20 rating ensure durability in both fixed and mobile installations. It integrates multiple control interfaces ( ILDA In/Out , DMX In/Out , RJ45 In/Out ), auto-run modes, sound, and software programming for 2D and 3D patterns.

Main features

• Laser power: 12 W RGB (semiconductor)
• Scanning speed: 25 kpps
• Uniformity: > 98%
• Beam divergence: < 1.2 mrad
• Laser window: 5.5 mm
• Modulation: 0–5 V analog / TTL up to 50 kHz
• Interfaces: ILDA In/Out, DMX512 In/Out, RJ45 In/Out
• Modes: Auto, Sound, Software Programming (2D/3D patterns)
• DMX Channels: 10 CH / 18 CH
• Consumption: 250 W
• Power supply: AC 100–240 V, 50/60 Hz
• Laser class: Class IV (IEC 60825)
• Certifications: CE, RoHS, UL, FCC, SAA
• Environment: Indoor, IP20
• Working temperature: 15 °C–45 °C

Product benefits

• Striking visuals with bright colors and precise blends
• Customizable 2D/3D patterns and animations for each show
• Professional control via ILDA, DMX and Ethernet networks
• High reliability thanks to the integrated cooling system and protections
• Easy installation with RJ45 port and standard XLR connection
• Low maintenance: no lamp replacement and long operating life

Use cases

• Concerts and festivals: long-range laser mapping and musical synchronization
• Discos and clubs: dynamic animation effects on the dance floor
• Theater and stage productions: ambient lighting and shape projections
• Corporate shows and trade shows: enhancing spaces with laser graphics and logos
• Indoor outdoor events: high-visibility coverage of large areas

Frequently Asked Questions

• How do you control the projector?
  Via ILDA protocol with dedicated software, DMX512, or RJ45 for networks; it also features automated modes and sound response.
• What is the maximum projection distance supported?
  Up to 200 m, with optimal performance between 30 and 100 m for maximum definition.
• What maintenance does it require?
  Periodic cleaning of the laser window and fan inspection; no lamp replacement required.
• Is it safe to use?
  It has Class IV certification (IEC 60825) and overcurrent and overvoltage protections.

Description for projects

12W RGB laser projector, 25 kpps scanning, divergence < 1.2 mrad, 5.5 mm window, uniformity > 98%, 0–5 V / TTL up to 50 kHz modulation, ILDA/DMX/RJ45 interfaces, auto/sound/2D/3D pattern modes, 10/18 DMX channels, 250 W consumption, 100–240 V 50/60 Hz power supply, Class IV, CE, RoHS, UL, FCC, SAA certifications.
