Fuzzix PLF20 - Party Par RGBAW-UV DMX

Fuzzix PLF20 - Party Par RGBAW-UV DMX

The Fuzzix PLF20 takes your party to the next level with four high-power 12W RGBAW-UV 6-in-1 LEDs, delivering an exceptional color spectrum and intense brightness. Its robust ABS housing and lightweight metal stand ensure durability and easy installation, while the included remote control allows you to independently adjust colors to create instantly customized atmospheres. Full DMX connectivity, built-in sound-to-light mode, and Master/Slave synchronization make it easy to integrate into any professional lighting system or stand-alone installation.

Main features

• 4 6-in-1 RGBAW-UV LEDs of 12 W each (Red, Green, Blue, Amber, White, Ultra Violet).
• Pre-programmed color macros and individual control via remote control.
• Operating modes: DMX (6 or 10 channels), Automatic, Sound activated, Master/Slave.
• 30° beam angle and 57° field angle for efficient light coverage.
• Luminous emittance of 3,185 lx at 1 m.
• IP20 protection rating; durable ABS housing with metal bracket.
• Control panel with LED display and intuitive buttons.
• Power consumption 0.165–0.296 A; power supply 100–240 VAC 50/60 Hz (IEC).
• Compact dimensions 150 × 150 × 70 mm; weight 0.35 kg.

Product benefits

• Allows vivid color displays and smooth transitions without the need for additional filters.
• Easy plug & play setup with automatic and sound modes.
• Easy integration into professional DMX networks for custom shows.
• No fan maintenance thanks to its passive cooling.
• Compact and lightweight design, ideal for mobile DJs and quick setups.

Use cases

• DJ sets and electronic music tours that require dynamic environments.
• Party venues, pubs and lounges where a visual focal point is sought.
• Corporate events and banquets with personalized color ambiance.
• Theaters and auditoriums for background lighting and special effects.

Frequently Asked Questions

• How do you daisy chain Master/Slave?
  In Master/Slave mode, connect the DMX OUT of the master unit to the DMX IN of the slave units; they will automatically follow the master's settings.
• Can I use it without a DMX table?
  Yes, it has Auto and Sound On modes to operate autonomously without an external controller.

Description for projects

LED Par with 4 × 12 W RGBAW-UV 6 in 1, macro color mixing, DMX modes (6/10 channels), Auto, Sound and Master/Slave, beam angles of 30° and field of view of 57°, emittance of 3,185 lx @ 1 m, IP20, ABS housing with metal support, LED control panel, remote control, consumption 0.165–0.296 A, power supply 100–240 VAC 50/60 Hz, dimensions 150 × 150 × 70 mm, weight 0.35 kg.
