MuxLab 500600 - Remote Infrared Extension Kit with Signal Pass-Through over Cat5e/6
Optimize the control of your audiovisual systems with the MuxLab 500600 , a high-performance infrared (IR) extension kit designed to overcome physical barriers in professional and residential installations. This system allows you to control video and audio equipment (such as DVD players, set-top boxes, video matrices, or satellite receivers) hidden in enclosed closets, server rooms, or remote locations, at an impressive distance of up to 670 meters .
Unlike conventional extenders, the MuxLab 500600 stands out for its intelligent engineering focused on cable efficiency. The system uses twisted-pair cable (Cat 5e or Cat 6) for transmission, but only requires a portion of the cable's bandwidth. Thanks to its terminal block connections, the device allows you to utilize the spare copper wires in the network cable to transmit additional low-voltage signals, such as composite video or audio, thus maximizing the existing infrastructure without the need for additional cable runs.
The kit includes everything needed for immediate setup: a compact transmitter and receiver module, a reliable external power supply, and the essential IR components (sensor and emitter). Its compact, robust housing design allows for discreet integration behind televisions, projectors, or within technical racks, ensuring a clean and professional installation.
Main features
-
Extended Range: IR signal transmission capability up to a maximum distance of 670 meters, ideal for large buildings, auditoriums or multi-story homes.
-
Efficient Connectivity: Uses standard Cat 5e or Cat 6 cabling, economical and easy to install.
-
Terminal Block (Pass-Through): Incorporates screw terminals that allow the passage of other signals (data, audio or video) using the twisted pairs not occupied by the IR signal.
-
Universal Compatibility: Works with the vast majority of remote controls and AV equipment on the market.
-
Complete Kit: Turnkey solution that integrates the transmission/reception electronics and the necessary infrared peripherals.
Benefits for the integrator and the user
For the end user , this device eliminates the need to have equipment "in plain sight." It allows for minimalist environments where only the screen is visible, while bulky set-top boxes and players remain hidden and secure in a ventilated cabinet or technical room, maintaining complete control from the sofa or conference table.
For the professional installer , the MuxLab 500600 offers unparalleled flexibility. The ability to use a single Cat cable to transmit IR along with other analog signals dramatically reduces working time and material costs. Furthermore, the terminal block connection ensures a secure and durable fix, resistant to vibration and accidental disconnections.
Use cases
-
Home Theater Systems: Control of amplifiers and players located in closed cabinets to maintain the aesthetics of the living room.
-
Meeting Rooms and Auditoriums: Management of projectors and videoconferencing equipment located on the ceiling or in technical rooms far from the podium.
-
Digital Signage: Remote control of screens and media players distributed in shopping centers or airports.
-
Educational Classrooms: Centralization of audiovisual equipment in security cabinets, allowing the teacher to control them from their desk.
Frequently Asked Questions
-
What type of cable should I use for the installation?
It is recommended to use standard Cat 5e or Cat 6 network cable to ensure the maximum range of up to 670 meters and a clean signal transmission.
-
Does the system require electrical power?
Yes, the kit includes an external power supply that connects to the system to amplify and manage the IR signal over long distances.
-
Can I control more than one device with this kit?
The base system includes one emitter, but the unit is technically capable of handling multiple sources if additional emitters or splitters compatible with the MuxLab infrastructure are used, depending on the specific configuration.
-
What is the function of terminal blocks or terminal blocks?
They allow the physical connection of the network cable wires and provide access points to the wire pairs that the IR system does not use, allowing it to send other signals over the same cable simultaneously.
Project description
Point-to-point infrared (IR) control extension system designed for long-range transmission over Cat 5e or Cat 6 twisted-pair (UTP/STP) cabling. The device supports distances of up to 670 meters between the source and destination. The unit consists of a transmitter and receiver kit equipped with terminal blocks that facilitate connection and allow pass-through of additional low-voltage signals through unused wire pairs. The package includes an external 110-220V power supply, one IR transmitter (model 500999), and one IR receiver (model 500998). Dimensions per module: 61 x 57 x 25 mm.
