beamZ Moon Flower 2.0 - RGBAW 72×5 mm moonflower effect with 4-channel DMX, glass lens and IR remote control
The beamZ Moon Flower 2.0 is a compact and robust moonflower effect that projects defined, multi-colored beam patterns thanks to its 72 x 5mm RGBAW (red, green, blue, amber, and white) LEDs and glass lens , which provides sharper color reproduction. Designed for mobile DJs, live performances, and fixed installations, it operates in standalone mode with 9 pre-programmed shows , syncs to the music with adjustable sensitivity, or is controlled via 4-channel DMX (3-pin XLR connection), allowing control of colors, strobe, and speed. It includes an IR remote control , a durable metal housing , and a control panel with a display for quick setup. With a 25° beam angle , 0–20 Hz strobe , and universal 100–240 V~ 50/60 Hz power supply, it offers reliable performance with plug-and-play installation , saving time and wiring.
Main features
-
Light source: 72 x 5mm RGBAW LEDs for vivid colors (R/G/B/Amber/White).
-
Optics: Glass lens for clean colors and a 25° beam that covers walls and ceiling with crisp patterns.
-
Control modes: DMX 4 channels , automatic (9 shows), sound-activated with adjustable sensitivity and master/slave .
-
Functions: strobe 0–20 Hz , quick program selection and adjustable speed.
-
Connectivity: DMX in/out 3-pin XLR ; local control via display and buttons.
-
Remote control: IR remote included for changing mode, speed, sensitivity and color.
-
Construction: sturdy metal chassis , black color, for indoor use.
-
Format and power: 280 x 145 x 110 mm; 0.95 kg; 100–240 VAC 50/60 Hz; nominal current 0.15–0.08 A.
Product benefits
-
Immediate impact without complications: plug and play, with 9 internal programs and sound mode for quick events.
-
Scalable control: from IR remote and front panel to full integration into 4ch DMX .
-
Richer colors than RGB: the amber and white channels expand the palette for warm, pastel, and clean white environments.
-
Designed for the road: metal casing and stable electronics for intensive use on tours and installations.
-
Easy assembly: lightweight form factor, included mounting bracket and standard XLR connectivity.
Use cases
-
Mobile DJ and private parties: a leading effect that fills the room with dynamic beams.
-
Live performances: reinforcement of small/medium stages with patterns on walls and ceiling.
-
Fixed installations: bowling alleys, clubs and recreational rooms with autonomous operation and simple maintenance.
-
Corporate and social events: versatile ambiance with DMX control when required.
Frequently Asked Questions
-
How many LEDs and what colors does it include? 72 x 5mm LEDs with RGBAW mix (R, G, B, Amber and White).
-
Does it have DMX? Yes, 4 DMX channels with color, program, and speed control.
-
Does it include a remote control? Yes, an IR remote control for basic remote operation.
-
What is the beam angle? Approximately 25° .
-
Can it be used to the rhythm of the music? Yes, it has an internal microphone with adjustable sensitivity .
Installation and control tips
- Position the unit at a height of 2–3 m with a slight incline to better distribute the beams across the ceiling and perimeter.
- In sound mode , calibrate the sensitivity to the actual room level to avoid erratic triggering.
- If you work via DMX , use the color channel for quick access to RGBAW combinations and the speed channel to synchronize the show's dynamics.
- Keep the lens clean with a soft cloth and avoid solvents to preserve beam sharpness.
Project description
Moonflower effect with 72 x 5 mm RGBAW LEDs , glass lens , 25° beam angle , 4-channel DMX , automatic (9 shows), sound-activated and master/slave modes, 0–20 Hz strobe , IR remote control , DMX in/out XLR 3 pins , display , metal housing ; power supply 100–240 VAC 50/60 Hz , current 0.15–0.08 A ; 280 x 145 x 110 mm , 0.95 kg , black color.
