JBL Professional VTX-F12 - 12" 2-Way Bi-Amplified System with 90x50 Driver and D2 Motor

Out of stock
SKU: VTX-F12 EAN13: 691991012907
(0)
3.109,54 € inc. VAT

If you have any questions about this product, we can assist you by filling out the contact form

Ask an expert

Chat Email +34 621046470
The VTX F Series is a line of multi-purpose loudspeakers designed to offer sound production companies a variety of flexible options for deploying high-quality audio, whether as a standalone FOH system, a satellite and subwoofer system (with the complementary VTX F18S), or as a floor monitor and stage fill speaker. Features? D2430K D2 Dual diaphragm dual driver? Transition waveguide (90° x 50°)? 2-way bi-amplified system? BSS Audio OmniDriveHD V5 processing? For use with Crown iTechHD and Crown VRack? JBL HiQnet Performance Manager control?
  • Brand:JBL Professional
  • Model:VTX-F12
  • System type:2-Way Bi-Amplified Multi-Purpose Speaker (12")
  • Nominal coverage:90° (H) × 50° (V)
  • Frequency range (−10 dB):51–21.5 kHz (Short Throw, free) / 44–21.5 kHz (Monitor, half-space)
  • Frequency response (±3 dB):69–20 kHz (Short Throw) / 58–20 kHz (Monitor)
  • Maximum peak SPL (1 m):132 dB (Preset: VTX F12 80)
  • Band sensitivity:LF 96 dB; HF 108 dB (1 W/1 m)
  • Nominal impedances:LF 8 Ω; HF 20 Ω
  • Power handling (AES 2 h):LF 1000 W continuous / 4000 W peak; HF 200 W continuous / 800 W peak
  • LF Transducer:1 × JBL 2262H, 12", 76 mm coil, Neodymium Differential Drive, Direct Cooled
  • HF Transducer:1 × JBL D2430K (D2), dual diaphragm and dual 76 mm coil, 38 mm (1.5") exit
  • Connectivity:4 × Neutrik Speakon NL4 (1± LF; 2± HF)
  • Assembly and rigging:35mm mast socket; 16 × M10 points; optional VTX-F12-UB bracket; SS5-BK rod (with F18S)
  • Wedge angle:53° (symmetrical enclosure)
  • Construction of the enclosure:18mm Baltic birch plywood (11 layers), DuraFlex finish; 14-gauge steel grille with acoustic mesh
  • Dimensions (H × W × D):548.6 × 396.2 × 304.8 mm
  • Net weight:19.1 kg
  • Recommended processing:BSS OmniDriveHD V5; management with JBL HiQnet Performance Manager; Crown I-Tech HD / VRack amplification
