JBL PROFESSIONAL

JBL Professional VLA-C125S - Dual 15" Differential Drive® Linear Array Subwoofer (IP55)

Out of stock
SKU: VLA-C125S EAN13: 691991010385
(0)
8.865,89 € inc. VAT

If you have any questions about this product, we can assist you by filling out the contact form

Ask an expert

Chat Email +34 621046470
The VLA-C125S uses proven JBL technology components, with dual-unit 15” Differential Drive® transducers. The enclosures feature multi-layer reinforced fiberglass and steel end panels. The grilles are zinc-coated, powder-coated, made of 14-gauge perforated steel with acoustically transparent black grille fabric, a hydrophobic mesh underlay, and a weatherproof track system. The rigging system is inherent to the system design. Angles between enclosures are selected when the array is assembled. Other accessories include a rigging frame, drawbar, and cardioid kit. Features: Compact line array module optimized for permanent installation applications Advanced technology component transducers for low weight and high performance IP55-rated outer enclosure for dust and water protection Complete mounting points to create a line array configuration Fiberglass enclosure construction and weather-resistant components Dual 15? transducers
  • Brand:JBL Professional
  • Model:VLA-C125S
  • Guy:Dual 15" line array subwoofer for fixed installation
  • LF Transducers:2 × 15" JBL 2275H, dual coil 76 mm (3"), Neodymium Differential Drive®, Direct Cooled™
  • Frequency range (−10 dB):52–210 Hz
  • Frequency response (±3 dB):62–123 Hz
  • Sensitivity (2.83 V/1 m):98 dB
  • Maximum SPL (1 m):127 dB continuous / 133 dB peak
  • Nominal impedance:4 Ω (min. 3.0 Ω @ 195 Hz)
  • Maximum input voltage:80 VRMS (160 V peak)
  • IEC power rating (pink noise):1600W cont. (6400 W peak, 2 h); 800W cont. (3200 W peak, 100 h)
  • DSP Presets:VLA-C125SSuband VLA-C125SLF Array
  • Recommended amplifiers:Crown DCi 2|2400N / 4|2400N (integrated DSP)
  • Construction of the enclosure:Fiberglass with finishgel coatand internal reinforcement of 18 mm birch plywood
  • Grille and protection:14-gauge zinc-coated perforated steel, acoustic fabric, and hydrophobic mesh
  • Environmental protection:IP55 (IEC 529)
  • Terminals:CE barrier terminals with coverstouch-proof, up to 5.2 mm² (10 AWG)
  • Inter-box angles:C125S↔C125S 0°; C265 below 0°/5°; C2100 below 0°/7.5°
  • Dimensions (H × W × D):508 × 848 × 634 mm
  • Net weight:56.7 kg
  • Colors:Black (-BK) / Gray (-GR, similar Pantone 420C)
  • Includes:2 VLA-C125S joining plates, M10 × 35 mm stainless steel screws, decorative caps
  • Optional:VLA-C-SB (suspension bars),Pull-Back Bar, VLA-C125S-ACC cardioid kit
  • Type New
  • Vendor JBL PROFESSIONAL
  • SKU VLA-C125S
  • Bar-code 691991010385

Buy JBL Professional VLA-C125S - Dual 15" Differential Drive® Linear Array Subwoofer (IP55)
