IK Multimedia AmpliTube X-GEAR X-DRIVE - Digital Distortion Pedal

IK Multimedia AmpliTube X-GEAR X-DRIVE – Digital distortion pedal with 16 algorithms, USB and MIDI

The AmpliTube X-DRIVE is the X-GEAR series gain pedal that brings the same tone you design in the studio to your pedalboard. Its DSP employs 16 overdrive , distortion, and fuzz algorithms with an X-MODE mode to further push character and feedback . The hardware runs on 24-bit/192 kHz converters , 5 Hz–24 kHz response, and 123 dB of dynamic range, with selectable true or soft bypass to preserve your signal. In addition to the main output, it features a CAB SIM output with 5 onboard cabinet IRs and a headphone output , so you can go direct to PA/FRFR or practice silently. It includes the X-DRIVE plugin for use in AmpliTube 5 SE and the X-GEAR Librarian manager for organizing up to 300 presets (50 factory presets). With MIDI In/Out , expression input/footswitch , and a USB audio interface with wet/dry routing, it's ready for the studio and live.

Main features

• 16 gain algorithms with dedicated controls and X-MODE for extended behaviors.
• Reference Audio : 24-bit/192 kHz, 5 Hz–24 kHz , 123 dB dynamic range; selectable true/soft bypass .
• Guitar-oriented connectivity : INPUT , OUTPUT , CAB SIM OUT (with 5 IRs), and HEADPHONES ; MIDI In/Out , EXT. CONTROL (expression or single/double footswitches), and USB for interface and Librarian.
• AmpliTube Integration : Includes AmpliTube 5 SE and the X-DRIVE plugin for designing presets and transferring them to the pedal; up to 300 storable presets .
• Anodized aluminum chassis , high-contrast display, and 3 footswitches (A/B/C) for live performance.

Models included (16)

MODERN ; METAL (based on BOSS® MT-2); MONARCH (Marshall® Guv'Nor); CAT (ProCo® Rat™); ORANGE (BOSS® DS-1); YELLOW (BOSS® SD-1); GREEN (Ibanez® Tube Screamer); DIODE (MXR® Distortion+); BLUE ; BOOSTER ; H-BOOST ; CRUSH ; OCTOFUZZ (MXR® Blue Box™); PURPLE (Roger Mayer™ Octavia); FUZZACE (Arbiter® Fuzz Face®); BIG-FUZZ (Electro-Harmonix® Big Muff Pi).

Product benefits

• Same tone in the studio and on stage : design in AmpliTube, save to the pedal, and maintain character with consistent tails/settings.
• Fast workflow : presets organized by banks and remote control via MIDI or expression pedal.
• Connection versatility : CAB SIM output with 5 IRs for PA/FRFR and headphones for silent practice.

Frequently Asked Questions

• How many presets does it hold? Up to 300 (the pedal includes 50 by default).
• Can it be used as an audio interface? Yes, via USB with wet/dry routing and monitoring between the pedal and computer.
• Does it include a power supply? Yes, a 9V DC center-negative adapter .

Description for projects

Distortion/overdrive/fuzz pedal with 16 algorithms and X-MODE . 24-bit/192 kHz converters, 5 Hz–24 kHz response, 123 dB dynamic range, true/soft bypass . Presets: 50 factory / 300 maximum. Connections: Input , Output , Cab Sim Out (5 IRs), Headphones , MIDI In/Out , Ext. Control (expression/footswitch), USB . Dimensions 175 × 145 × 58 mm ; weight 906 g . Includes X-DRIVE plugin, AmpliTube 5 SE, Librarian, 9 V power supply and USB cable.
