beamZ Hyaden - Mobile bar with 7 RGBW LEDs and 8 red laser beams (638 nm) for aerial effects

beamZ Hyaden - Mobile bar with 7 RGBW LEDs and 8 red laser beams (638 nm) for aerial effects

The Hyaden beamZ is a motorized light bar that combines seven 3W 4-in-1 LEDs (RGBW) with eight 638nm red lasers , creating a hybrid effect that fills the space with crisp fat beams and precise laser patterns. Designed for indoor use , it integrates TTL modulation in the laser section for defined paths and offers 180° tilt movement, ideal for sweeping across dance floors, backdrops, and ceilings in venues, clubs, and events. It includes standalone modes with pre-programmed shows and patterns, sound activation with adjustable sensitivity, and a master/slave function for synchronizing multiple units without a console.

For advanced control, the Hyaden offers 10 and 23-channel DMX , with 3-pin XLR input/output . The control panel with LED display streamlines field setup, while power daisy-chaining via P-Con in/out connectors simplifies wiring on trusses and structures. With its robust bar-style construction (1000 × 83 × 164 mm) and a weight of 7.2 kg, it's a reliable solution for mobile DJs, venues, and rental companies seeking a versatile fixture with RGBW mixing and a 499 mW red laser .

Main features

• Hybrid LED + laser: 7 4-in-1 LEDs of 3W (RGBW) and 8 red laser beams at 638 nm.
• Defined aerial effects: fat beam LED beams and sharp laser patterns by TTL modulation .
• Movement: 180° tilt for wide, dynamic sweeps.
• Flexible control: DMX 10/23 channels , standalone , master/slave and sound to light with adjustable sensitivity.
• Integrated shows: pre-programmed shows and patterns ready to use.
• Professional connectivity: DMX 3-pin XLR IN/OUT and P-Con IN/OUT for power daisy-chaining.
• Interface: control panel with LED display .
• Intended use: indoors (without ILDA).

Product benefits

• Visual impact with a single unit: combines RGBW wash/beam and laser projection, reducing the number of fixtures required.
• Programming tailored to your needs: 23 channels for detailed control or 10 channels for quick assembly.
• Cleaner setups: P-Con and XLR daisy-chaining minimizes cables and installation time.
• Immediate operation: standalone modes and sound to light for express shows without a console.
• Greater visibility: 638 nm red laser with 499 mW for intense beams in haze environments.

Use cases

• Clubs and discos: aerial sweeps and laser patterns on the dance floor.
• Indoor events and festivals: front/rear truss line reinforcement with moving effects.
• Mobile DJ and rental: pre-programmed shows and agile cabling for quick setups.
• Theatre and performance: contour effects and light skies when using haze .

Frequently Asked Questions

• Is it controlled by ILDA? No. Without ILDA ; control is via DMX or in standalone modes.
• Is it suitable for outdoor use? No. The unit is designed exclusively for indoor use .
• Do I need smoke/haze? Recommended to make LED and laser beams visible in the air.
• What power connectors does it use? P-Con IN/OUT for daisy-chaining multiple bars on the same line.

Project description

Indoor moving light bar with 7 x 3W RGBW LEDs and 8 x 638nm red lasers ( 499mW ), 180° tilt , TTL modulation, Standalone/Master-Slave/DMX modes ( 10/23 channels ), DMX 3-pin XLR IN/OUT , P-Con IN/OUT , LED panel . Power supply: 100–240V~ 50/60Hz , current consumption: 0.833–0.434A . Dimensions: 1000 × 83 × 164 mm . Weight: 7.2 kg . Accessories: mounting bracket and power cable .
