Electro-Voice EVID-S12.1B - 12" Passive Installation Subwoofer (Black)

Electro-Voice EVID-S12.1B - 12" Passive Installation Subwoofer (Black)

The Electro-Voice EVID-S12.1B is a 12" passive subwoofer module for professional indoor and outdoor (weatherized) installations, designed to reinforce the low zone next to any EVID-S system or other installation satellites. It incorporates a 12" high-excursion woofer with dual voice coils that accepts L / R stereo input and offers crossover outputs to feed up to four satellites at once, simplifying the system without external processing. Its slot-loaded , trapezoidal -shaped enclosure, made of reinforced MDF with steel fixings , optimizes bass response and facilitates wall or corner mounting with the supplied hardware. It delivers a range of 40–140 Hz (-10 dB) , sensitivity of 104 dB and up to 127 dB SPL ( 133 dB peak ) with 200 W continuous / 800 W peak at 8 Ω . Finished in black RAL 9004 , paintable to integrate into any space.

Main features

• 12" high-excursion transducer with dual voice coils for simultaneous L/R inputs .
• Integrated crossover panel with filtered outputs for up to 4 EVID-S satellites .
• Verified performance : 40–140 Hz (-10 dB), 104 dB sensitivity, 127 dB SPL max. (133 dB peak).
• Allowable power : 200 W continuous IEC (100 h) / 800 W peak; 8Ω .
• Slot-loaded MDF enclosure with steel fixings , optimized for wall or corner mounting.
• Connections using high reliability spring-loaded terminals .
• Weatherized (suitable for interior/exterior) and paintable finish for complete aesthetic integration.
• Wall hardware included for quick and secure installation.

Product benefits

• More bass with less equipment : the sub itself distributes the filtered signal to multiple satellites without an additional processor.
• Quick installation : trapezoidal format, included bracket and pressure terminals for quick wiring.
• Visual integration : paintable RAL 9004 black finish and discreet grille for commercial and hospitality spaces.
• Reliability of a robust MDF design with steel fixings and professional specifications.

Use cases

• BGM/FGM in restaurants, retail, fitness, hotels and leisure , where greater bass extension is required.
• Multipoint zones with several EVID-S satellites fed from the sub itself.
• Semi-outdoor applications (covered terraces, porches) with protected installation.

Frequently Asked Questions

• Does it support stereo signals? Yes. The dual-voice coil woofer accepts L/R simultaneously.
• Can I feed satellites from the sub? Yes, the crossover panel offers filtered outputs for up to four EVID-S boxes .
• Does it have an IP rating? It says weatherized for indoor/outdoor use; no specific IP rating is specified.

Description for projects

Electro-Voice EVID-S12.1B passive subwoofer; 12" high-excursion dual-voice voice coil ; 200 W RMS / 800 W peak ; 8 Ω ; sensitivity 104 dB (1 W/1 m, 60–100 Hz, 1/8 space); max. SPL 127 dB (133 dB peak); 40–140 Hz (-10 dB) ; spring-loaded connectors ; crossover panel with outputs for up to 4 satellites; slot-loaded MDF enclosure with steel fixings; weatherized ; wall fittings included; 413 × 584 × 303 mm ; 17.8 kg ; black RAL 9004 finish, paintable.
