Electro-Voice ELX200-12S-W - 12" Passive PA Subwoofer (White) with Dual NL4s and M20 Base

Electro-Voice ELX200-12S-W - 12" Passive PA Subwoofer (White) with Dual NL4s and M20 Base

The Electro-Voice ELX200-12S-W is a 12" passive subwoofer module designed to complement ELX200 series full-range systems and other PA arrays. It integrates an EVS-12L transducer optimized for powerful low end into a 15mm plywood enclosure with internal bracing and a heavy-duty polyurea finish , ideal for intensive use. Professional hardware includes an M20 threaded satellite pole socket , dual carrying handles , and dual NL4 input/link connectors . The W (white) version facilitates aesthetic integration into installations and events where the equipment needs to be out of sight.

It offers a range (−10 dB) of 33–300 Hz and response (−3 dB) of 42–220 Hz , with a max. SPL of 129 dB . Its power handling is 400 W continuous / 1600 W peak , with a nominal impedance of 8 Ω ( min. 6.9 Ω ) and axial sensitivity of 93 dB (1 W/1 m). Compact dimensions of 397 × 445 × 457 mm and a net weight of 17.2 kg complete a versatile subwoofer for portable and fixed applications.

Main features

• LF transducer: 1 × EVS-12L (300 mm / 12").
• Acoustic performance: 33–300 Hz (−10 dB); 42–220 Hz (−3 dB); 129 dB max. SPL.
• Power and impedance: 400 W continuous / 1600 W peak; 8 Ω nominal ( min. 6.9 Ω ); 93dB (1W/1m).
• Connectivity: 2 × NL4 wired in parallel for input and link.
• Enclosure: 15mm plywood with reinforcements, polyurea finish and 18 AWG powder-coated steel grille.
• Satellite mount: M20 threaded base on top.
• Transport: two side handles for comfortable handling.
• Color: white ( -W version ), also available in black.
• Recommended filter: high pass at 42 Hz .

Product benefits

• Defined bass in a lightweight format: punch and LF extension with a compact and robust enclosure.
• Quick and clean setup: dual NL4s for daisy-chaining subwoofers or satellites; M20 socket for 2.1/2.2 systems with ELX200.
• Professional durability: 15mm wood, polyurea finish and steel grille designed for daily use.
• Aesthetic integration: white finish for corporate, hospitality, religious and educational environments.

Use cases

• Events and rentals: M20 pole mounting and NL4 link for agile deployments.
• Fixed installations: auditoriums, restaurants, hotels, and classrooms that require bass reinforcement without sacrificing aesthetics.
• Mobile bands and DJs: maximum output of 129 dB with reduced footprint.

Frequently Asked Questions

• Which filter should be used? A 42 Hz HPF is recommended to protect the transducer and optimize performance.
• Can I use it with speakers other than the ELX200 series? Yes, as long as the crossover and amplification are appropriate for the impedance/power.
• Are NL4s parallel? Yes, they allow input and link to another element.

Description for projects

Electro-Voice ELX200-12S-W (white) passive subwoofer; LF EVS-12L ; 33–300 Hz (−10 dB), 42–220 Hz (−3 dB); 129 dB max. SPL; 400 W RMS / 1600 W peak ; 8 Ω nominal ( min. 6.9 Ω ); 93 dB (1 W/1 m); 2 × NL4 ; 15 mm plywood enclosure with polyurea finish; 18 AWG steel grille; M20 base; 397 × 445 × 457 mm (H × W × D); 17.2 kg (net).
