CROWN DCi 4|300N - Four-channel power amplifier, 300W @ 4Ω with Blu Link, 70V/100V / Compliant with EN 54-16

CROWN DCi 4|300N – Four-channel power amplifier, 300 W @ 4 Ω with BLU-Link and 70 V/100 V (EN 54-16)

The CROWN DCi 4|300N integrates DriveCore™ technology into a high-performance installation amplifier with four independent 300W channels at 4 Ω and constant voltage outputs of 300W at 70 Vrms and 100 Vrms without the need for external transformers. Its BLU-Link™ digital audio engine carries up to 256 channels with low latency and, together with balanced analog inputs and a priority router, ensures signal continuity. The HiQnet™ over TCP/IP protocol enables remote network monitoring and control, while programmable GPIO ports and onboard DSP (LevelMAX™ limiters, input/output EQ, crossover, delay, matrix and line monitoring) provide maximum flexibility. It complies with the EN 54-16 standard for voice alarm systems and features front-to-back forced cooling and a universal power supply with active PFC for efficient and reliable operation.

Main features

• Four channels of 300 W @ 4 Ω; 150W @ 2Ω; 300W @ 8Ω; 150W @ 16Ω; 300 W at 70 Vrms; 300W at 100Vrms
• Bridge Mono: 300 W @ 4 Ω; 600W @ 8Ω; 600W @ 16Ω; 600W at 140Vrms; 600W at 200Vrms
• BLU-Link™ digital for audio and DSP over Cat5e (up to 256 channels)
• Balanced analog and BLU-Link digital inputs with priority switching
• Remote monitoring and control via HiQnet™ TCP/IP
• Programmable GPIO ports for external control, preset recall, and fault reporting
• Integrated DSP: LevelMAX™ limiters, input/output EQ, crossover, delay, matrix, signal generator, and line monitoring
• EN 54-16 Compliant for voice applications in life safety systems
• Variable front-to-back forced cooling
• Universal power supply 100–240 VAC, 50/60 Hz with active PFC; IEC 15 A connector
• Dimensions 48.3 × 8.9 × 35.6 cm; weight 9.12 kg

Product benefits

• High rack density: four channels in 2 U to optimize installation space.
• Signal redundancy: automatic switching of inputs for maximum continuity.
• Continuous monitoring: HiQnet™ and GPIO to monitor status, charging and faults.
• Quality Audio: High-Resolution DSP and BLU-Link™ with Low Latency.
• Safe installation: EN 54-16 certification for voice alarms in security systems.

Use cases

• Public address and voice evacuation systems in hotels, hospitals, and public buildings.
• Audio distribution in shopping malls, airports, and transportation stations.
• Sound reinforcement for auditoriums, theaters, and convention centers with zoning and remote control.

Frequently Asked Questions

• How is the EN 54-16 pilot tone fed? It is generated and monitored by HiQnet Audio Architect® via BLU-Link™.
• Can channels be bridged? Yes; in Bridge Mono, each pair delivers up to 600 W into 8 Ω.
• What voltage range does it accept? Universal operation: 100–240 VAC, 50/60 Hz.

Description for projects

2U rack amplifier with four 300W @ 4 Ω channels, BLU-Link™ digital, HiQnet™ TCP/IP, DSP with LevelMAX™ and filters, programmable GPIOs, EN 54-16, forced cooling, 48.3×8.9×35.6 cm, 9.12 kg.
