Triton Blue CC-575 – CMY color changer for MSR 575/2 lamp (without lamp) – 4 DMX channels, shutter and dichroic wheel

Triton Blue CC-575 – CMY color changer for MSR 575/2 lamp (without lamp) – 4 DMX channels, shutter and dichroic wheel

The Triton Blue CC-575 is a high performance CMY color changer designed for shows, theater and events where a wide color palette and smooth transitions are required. It incorporates continuous subtractive CMY mixing , color wheel with 7 dichroic filters + white and color temperature correctors , as well as configurable rainbow effect. The dual-blade shutter allows strobe from 0 to 10 Hz and instant blackout. It is controlled by DMX-512 on 4 channels (16 bit) , has auto-programming , local or remote reset and memory of up to 48 scenes . It works with MSR 575/2 lamp (not included) and AC 110–220 V, 50/60 Hz power.

Main features

• Color mixing: Subtractive CMY for fine transitions and saturated colors.
• Dichroic wheel: 7 filters + white, with color temperature correctors and rainbow effect.
• Shutter/Strobe: double leaf, 0–10 Hz, blackout and random mode.
• Control: DMX-512, 4 channels (16-bit resolution), auto-programming and local/remote reset.
• Memory: storage of up to 48 internal scenes .
• Compatible lamp: MSR 575/2 (not included).
• Power supply: AC 110–220 V , 50–60 Hz.
• Construction: Robust unit for intensive use on tour and in professional installations.

Product benefits

• Wide color palette thanks to CMY + dichroic wheel with direct colors and CTO/CTB correctors.
• Agile operation : scene memory, self-programming and remote reset reduce adjustment times.
• Dynamic effects : fast strobe, rainbow effect and fluid changes between colors.

Use cases

• Theater and musicals : precise color transitions without light cuts.
• Corporate events and touring : pre-recorded corporate colors and looks with immediate recall.
• Television and live : combination of saturated colors and temperature-corrected whites.

Frequently Asked Questions

• Does it include a lamp? No. The CC-575 is supplied without a lamp and uses MSR 575/2 .
• Does it come with a visor? No, the visor is not included .
• How many DMX channels does it use? 4 channels with 16-bit resolution.

Description for projects

CMY color change with dichroic wheel (7 colors + white) , color temperature correctors and rainbow effect; dual-blade shutter with 0–10 Hz strobe ; 4-channel DMX-512 (16 bit) ; auto-programming , local/remote reset , 48 scene memory ; power supply AC 110–220 V, 50–60 Hz ; compatible with MSR 575/2 lamp (not included); weight 28 kg ; packaging dimensions 51 × 37 × 34 cm ; visor not included.
