BSS BLU-8V2WHT - Programmable Zone Controller

Out of stock
SKU: BLU-8V2WHT EAN13: 691991014017
(0)
1.166,76 € inc. VAT

If you have any questions about this product, we can assist you by filling out the contact form

Ask an expert

Chat Email +34 621046470
The BLU-8v2 is a HiQnet-compatible programmable zone controller capable of controlling a single zone, four zones, or eight zones in different operating modes. A simple control surface and informative visual feedback ensure that non-technical users can feel confident when making changes to an integrated AV system. What's different about the v2 version? The BLU-8v2 shares the same feature set and appearance as the original BLU-8, but benefits from a significant hardware upgrade. Beneath the surface, the BLU-8v2 has much in common with Soundweb London rackmount devices, and this revised hardware design offers a considerable improvement in network functionality. The BLU-8v2 is available in black or white.
  • Brand:BSS Audio
  • Model:BLU-8v2WHT
  • Guy:Programmable wall-mounted zone controller
  • Color:White (also available in black)
  • Modes of operation:Single (1 zone), Button (4 zones), Encoder (8 zones)
  • Physical controls:2 rotary encoders, 5 buttons
  • Indicators:9-segment LED meter; configurable RGB LEDs
  • Advanced Features:Sleep mode; PIN lock (4 digits); Locate button
  • Connectivity:Ethernet (RJ45) to Soundweb London network
  • Feeding:PoE (IEEE 802.3af) or 14–48 VDC per 2-way terminal
  • Consumption (max.):300 mA (referenced to 14 V DC)
  • Max network length:100 m (Cat 5 shielded)
  • Mounting:Built-in boxUS 3-gang(metal boxes are recommended)
  • Dimensions (H × W × D):122.96 × 169.96 × 50.52 mm
  • Operating temperature:0–40 °C
  • Includes:6-32 Screws,overlayLexan, label sheet and power connector (2-way terminal)
  • Configuration software:HiQnet London Architect (compatible with Audio Architect ecosystem)
  • Type Audio
  • Vendor BSS
  • SKU BLU-8V2WHT
  • Bar-code 691991014017
