beamZ Pro BAC552Z - Professional Aluminum PAR Spotlight with RGBW Zoom

beamZ Pro BAC552Z - Professional Aluminum PAR Spotlight with RGBW Zoom

The beamZ Pro BAC552Z represents the next generation of professional LED PAR lights, meticulously designed to offer exceptional versatility in both stage and architectural lighting projects. Its robust aluminum housing not only provides superior durability but also optimizes heat dissipation, complementing its efficient and quiet temperature-controlled cooling system. This light is a powerful and reliable lighting tool for any professional application.

Equipped with 19 x 15W 4-in-1 LEDs , the BAC552Z produces a rich, vibrant, and homogeneous RGBW (Red, Green, Blue, and White) color mix. Its large lens technology allows for precise and creative color customization. One of its most outstanding features is the motorized zoom , which offers an adjustable beam angle range of 8° to 35°, enabling smooth transitions from a focused, defined beam to a wide, diffused wash. This flexibility makes it the ideal choice for lighting designers looking to create dynamic and atmospheric effects.

For advanced creative control, the light features three individually controllable LED zones , enabling the creation of complex patterns, pixel-mapping effects, and dramatic color transitions. Its 0-100% electronic dimmer ensures smooth, flicker-free dimming, essential for high-quality productions.

Main Features

• Power and Color: Equipped with 19 LEDs of 15W each with 4 in 1 technology for flawless RGBW color mixing.
• Versatile Motorized Zoom: Adjustable zoom range from 8° to 35° that allows you to create both beam and wash effects.
• Creative Zone Control: Three independently controllable LED zones for creating complex visual effects.
• Professional Construction: Lightweight and durable aluminum casing that ensures durability and efficient, quiet cooling.
• Flexible Operating Modes: Operates in DMX mode (10 or 18 channels), standalone, master/slave and sound activated with adjustable sensitivity.
• Practical Features: Includes pre-programmed shows, 0-100% electronic dimmer, control panel with LED display and Powercon input/output connectors to daisy-chain the power supply of several units.
• Easy Assembly: It has a double handle that not only serves as a standard mounting support, but also allows for stable use as a floor stand.

Benefits for Lighting Professionals

The BAC552Z is ​​designed to simplify the workflow for lighting technicians and designers. The ability to link the power supply of multiple units via its Powercon connectors significantly reduces setup time and the amount of wiring required. Its versatility, combining beam and wash effects in a single unit, optimizes space and budget. The aluminum housing not only ensures a long lifespan but also makes it lightweight and easy to transport and install.

Use Cases

This PAR spotlight is the perfect solution for a wide range of applications. In concerts and on tours , its powerful output and dynamic zoom allow for the creation of impactful atmospheres. For theaters and stage productions , its quiet operation and precise color mixing are crucial. In architectural lighting , it is used to highlight facades, monuments, and structures with vibrant colors and controlled effects. It is also ideal for event rental companies, nightclubs, and permanent installations that require robust, reliable, and high-performance equipment.

Frequently Asked Questions

What type of DMX control does this spotlight offer?
The beamZ Pro BAC552Z can be operated via DMX using 10 or 18 channels, allowing everything from basic control to detailed management of the 3 LED zones and zoom.

Is it possible to link the power supply of several lights?
Yes, thanks to its Powercon input and output, several units can be daisy-chained to a single power outlet, simplifying electrical installation.

Is the fan noisy?
No, the cooling system is temperature controlled and has been designed to be highly efficient and low noise, making it suitable for environments that require silence, such as theaters.

Can it be used without a DMX controller?
Yes, the spotlight includes standalone operating modes with automatic programs and sound activation, as well as master/slave configuration to synchronize multiple units without the need for an external control console.

Project description

Professional PAR light with an aluminum housing, equipped with 19 x 15W RGBW LEDs. It features motorized zoom with a beam angle range of 8° to 35° and a field angle of 15° to 58°. It offers 10 or 18 channel DMX control, with 3 individually controllable LED zones. Operating modes include standalone, master/slave, and sound-activated modes. It has a 0-100% electronic dimmer, 3-pin XLR DMX connectors, and Powercon input and output connectors. Cooling is provided by a temperature-controlled fan system. Power supply: 100-240VAC 50/60Hz.
