Audibax Pro Monster 200 Hybrid - 200W LED hybrid moving head (spot/beam with frost and wash), 7–21° zoom and 18 DMX channels

Audibax Pro Monster 200 Hybrid — 200W LED hybrid moving head (spot/beam with frost and wash), 7–21° zoom, 18 DMX channels

The Audibax Pro Monster 200 Hybrid is a high-performance hybrid moving head that combines a 200W white LED (300W power consumption) with a 7–21° motorized zoom lens to go from concentrated beam/spot beams to a soft wash using a frost filter . With a 7,500K color temperature , 0–100% linear dimmer and 1–25 Hz stroboscope , it offers precise and dynamic looks for live performance, touring and installation.

The effects engine integrates a color wheel (9 + open, half color) , a static gobo wheel (10 + open) , a rotating gobo wheel (7 + open) and a 4-facet circular prism with bi-directional rotation . The fast, reliable mechanism provides 540° pan and 270° tilt with fine adjustment, controlled by 18 DMX channels in DMX/Master–Slave/Auto/Audio modes. The 180° reversible LCD screen speeds setup in any orientation and supports corporate gobos (Ø 21.8 mm; image 17 mm; max. thickness 1.2 mm) for event branding.

Main features

• Source : 200 W white LED (300 W unit), 7,500 K , average life 50,000 h .
• Optics and mixing functions : 7–21º zoom , frost for spot/beam to wash transition.
• Effects : 9 color wheel + open (half color), 10 static gobos , 7 rotating gobos , 4-facet prism , strobe 1–25 Hz , dimmer 0–100% .
• Movement : Pan 540° + fine / Tilt 270° + fine.
• Control : 18 DMX channels , DMX, Master–Slave, Auto and Sound Activated modes; 180° reversible LCD .
• Customizable gobos : accepts corporate gobos (Ø 21.8 mm; image 17 mm; 1.2 mm max.).
• Power supply : AC 100–240 V, 50–60 Hz ; IP20 .
• Dimensions/weight (unit) : 343 × 239 × 537 mm ; 14.5 kg . Packaging approx.: 59 × 45 × 45 cm (gross 17.8 kg).

Product benefits

• True versatility : a single spotlight covers a defined beam , spot with gobos and soft wash via frost and zoom.
• Unlimited creativity : dual gobo wheels, prism and half-color for rich scenes and corporate gobo branding.
• Professional operation : 18 DMX channels and reversible screen for quick mounting in any position.
• Touring reliability : fine-tuned pan/tilt mechanics and construction designed for rental and continuous installation.

Use cases

• Corporate events and trade shows : projection of logos, gobos, and clean looks on stages and stands.
• Clubs, festivals and concerts : powerful beams, strobe chases and textures with prisms and gobos.
• Theater and Fixed Installation : Smooth transitions and even coverage with frost and zoom.

Frequently Asked Questions

• How many DMX channels does it have? 18 channels , with DMX, Master–Slave, Auto, and Sound modes.
• What size gobo does it support? Ø 21.8 mm (image 17 mm , max. thickness 1.2 mm ).
• What's the zoom range? 7–21° to go from beam to spot/wash with frost.
• What is the lifespan of an LED? Approximately 50,000 hours .

Description for projects

LED hybrid moving head 200 W ( 300 W unit), 7,500 K ; zoom 7–21° ; pan 540° + fine / tilt 270° + fine; dimmer 0–100% , strobe 1–25 Hz ; 18 DMX channels , DMX/Master–Slave/Auto/Audio modes; color wheel 9 + open (half color); 10 static + 7 rotating (open) gobos; bidirectional 4-facet prism ; frost ; 180° reversible LCD ; brand gobos (Ø 21.8 mm / image 17 mm / 1.2 mm max.); AC 100–240 V, 50–60 Hz ; IP20 ; dimensions (unit) 343 × 239 × 537 mm ; net weight 14.5 kg ; packaging approx. 59 × 45 × 45 cm (gross weight 17.8 kg ).
