AKG CBL410PCC - Boundary Condenser Microphone with Cardioid Polar Pattern

AKG CBL410 PCC - Omnidirectional Boundary Microphone for Conferences with 3.5mm Mini Jack

The AKG CBL410 PCC is a boundary layer condenser microphone designed for voice overs in video conferencing and telepresence . Its omnidirectional capsule evenly captures participants around the table and, thanks to its surface mount, reduces early reflection artifacts, improving intelligibility. It's a plug & play device: it connects directly to the computer's 3.5mm microphone input and operates with the plug-in power supplied by the device itself, without installing drivers.

It offers a bandwidth of 20 Hz–20 kHz with a sensitivity of 3.88 mV/Pa and a signal-to-noise ratio of 58 dB(A) , and supports up to 120 dB SPL . It includes an additional connector to chain several microphones on the same table, with a recommendation of up to 4 units to maintain audio quality. Its low-profile design with a metal grille protects the capsule and goes unnoticed in meeting rooms. Available in black or white .

Main features

• Surface/boundary layer for voice with natural pickup around the table.
• Omnidirectional polar pattern with wide response 20 Hz–20 kHz .
• Direct connection to PC/Mac via 3.5 mm stereo mini-jack ; no drivers required.
• Plug-in power supply (1.5–5 V DC) from the computer's microphone input.
• Linkable via its IN input to expand coverage on tables (recommended up to 4 microphones).
• Solid specifications : sensitivity 3.88 mV/Pa , S/N 58 dB(A) , max SPL 120 dB , impedance 2 kΩ .
• Discreet and robust format with protective grille; dimensions 114 × 114 × 21 mm , weight 159 g .

Product benefits

• Instant installation in BYOD rooms: plug and play, no interfaces or software required.
• Optimal intelligibility in meetings thanks to the boundary layer effect and uniform reception.
• Scalability : Add more CBL410 PCCs to cover large tables while maintaining simple wiring.
• Wide compatibility with laptops and desktops that have a 3.5mm microphone input with plug-in power.

Use cases

• VoIP video conferencing in meeting rooms, classrooms, and offices.
• Distance learning and multi-speaker collaboration rooms.
• Voice note recording and quick minute-taking in a corporate environment.

Frequently Asked Questions

• How do you daisy-chain multiple mics? Connect the second CBL410 PCC to the IN jack of the first, and so on. To maintain quality, we recommend daisy-chaining no more than four mics .
• Do I need a USB interface? Only if your computer doesn't have a 3.5mm microphone input with plug-in power. In that case, use an interface/adapter with a microphone input.
• Does it include accessories? The set includes the microphone with a 1 m fixed cable terminated with a 3.5 mm mini jack .

Description for projects

AKG CBL410 PCC omnidirectional condenser boundary microphone; response 20 Hz–20 kHz , sensitivity 3.88 mV/Pa (−48 dBV) , S/N ratio 58 dB(A) , max. SPL 120 dB (1 % THD) , impedance 2 kΩ . Connection 3.5 mm stereo minijack , fixed cable 1 m . Power supply 1.5–5 V DC ( plug-in power ), max. consumption 0.5 mA . Dimensions 114 × 114 × 21 mm , weight 159 g . Can be daisy-chained (up to 4 units recommended).
