Audibax SRM102 - Professional 8-channel rack mixer for installations (5 mic + 3 aux, 4 outputs)

Audibax SRM102 - Professional 8-channel rack mixer for installations (5 mic + 3 aux, 4 outputs)

The Audibax SRM102 is a rackmount mixer designed to reliably manage multiple sources in bars, restaurants, hotels, retail spaces, and corporate environments . It features eight inputs (five microphone and three auxiliary) with two priority inputs , four outputs , and individual volume control per channel . Its ±10 dB bass and treble equalization allows you to adjust the tone to the room's acoustics, while the mute function simplifies priority management. Technically, it offers a frequency response of 30 Hz to 20 kHz (±3 dB) , distortion ≤ 0.1% at 1 kHz, and an auxiliary signal-to-noise ratio ≥ 66 dB , with a nominal 0 dBV output for driving stage amplifiers or other installation amplifiers. It is powered by AC 220 V / 50 Hz and has dimensions of 484 × 365 × 88 mm (unit), net weight 6.2 kg and packaging 530 × 440 × 195 mm (gross weight 8 kg), which simplifies the integration and logistics of the project.

Main features

• 8 inputs : 5 microphone + 3 auxiliary, with 2 priority inputs for alerts or messages.
• 4 outputs for distribution to installation stages/amplifiers.
• Independent volume control per channel and mute function .
• Equalization : bass ±10 dB (100 Hz) and treble ±10 dB (10 kHz).
• Performance : response 30 Hz–20 kHz (±3 dB), distortion ≤ 0.1 % (1 kHz), auxiliary S/R ≥ 66 dB.
• Levels : mic input sensitivity ≤ 3.2 mV (unbalanced), aux ≤ 300 mV; nominal output 0 dBV.
• Protections : AC fuse and stable operation for continuous use in commercial environments.
• Rack format : unit 484 × 365 × 88 mm; net weight 6.2 kg .

Product benefits

• Real versatility : combines microphones, background music and priority announcements in a single device.
• Simple operation : clear front controls and independent volume per channel for quick adjustments.
• Consistent sound : effective basic equalization and low-noise electronics for voice and background music.
• Professional integration : line level output ( 0 dBV ) for working with installation amplifiers and matrices.
• Reliability : designed for intensive use in fixed installations with fuse protection.

Use cases

• Hospitality and leisure : microphone mixing for announcements and background music.
• Corporate and education : multipurpose rooms, receptions and small/medium-sized auditoriums.
• Retail and sports centers : voice messages and playlists throughout the day.
• AV events and integration : as a zone preamplifier in 70/100 V systems (via external amplification).

Frequently Asked Questions

• Does it include phantom power for condenser microphones? The manufacturer does not indicate phantom power for this model; if you need phantom power, use an external preamp or a mixer with that function.
• How do priority inputs work? The device has priority inputs and a mute function to manage alerts; the specific muting logic depends on the installation.
• Can I connect it to a 70/100V installation amplifier? Yes. The SRM102 delivers 0 dBV line level ; connect it to the line input of the 70/100V amplifier.
• Is it suitable for continuous use? Yes, it is designed for professional installations with prolonged use and AC fuse protection.

Installation recommendations

• Plan the priority of inputs (alert microphones, emergency, etc.) before wiring.
• Adjust the gain and tone using real music and voice to balance the enclosure system.
• Respect the rack ventilation and adequate electrical protection (fuse and grounding).

Project description

Installation mixer, 8 inputs (5 mic, 3 aux) with 2 priority inputs; 4 outputs; volume control per channel; bass/treble EQ ±10 dB (100 Hz / 10 kHz); frequency response 30 Hz–20 kHz (±3 dB); distortion ≤ 0.1% at 1 kHz; auxiliary S/R ≥ 66 dB; mic sensitivity ≤ 3.2 mV and aux sensitivity ≤ 300 mV (unbalanced); output 0 dBV; AC power supply 220 V / 50 Hz; unit dimensions 484 × 365 × 88 mm; net weight 6.2 kg; packaging dimensions 530 × 440 × 195 mm; gross weight 8 kg.
