Audibax Wall 50 - Wall-mounted volume control 100V, 50W (11 positions, flush mount format)

Audibax Wall 50 - Wall-mounted volume control 100V, 50W (11 positions, flush mount format)

The Audibax Wall 50 is a volume control for 100V line systems that allows precise level adjustment in each zone without compromising sound quality. With a 50W handling capacity , it is suitable for background music and public address systems in retail, hospitality, educational, and corporate spaces. Its flush-mount design and white finish integrate discreetly, occupying minimal space ( 86 × 93 × 66 mm ).

Designed for 100V line operation , the Wall 50 facilitates zoned audio distribution with long cable runs and multiple speakers, while maintaining system efficiency. The stepped rotary selector control offers clean and repeatable attenuation, ideal for daily adjustments by non-technical personnel.

Main features

• Rated power: 50 W at 100 V.
• Step control: 11-position rotary selector for precise adjustment.
• Installation format: recessed in standard wall box .
• Dimensions: 86 × 93 × 66 mm; color: white.
• Application: local volume control by zone in 100V PA systems.

Product benefits

• Simple zone management : adjust the level in each room without touching the central amplifier.
• Clean installation : discreet recessed format compatible with standard wall boxes.
• Reliability at 100V : 50W handling suitable for background music and announcement circuits.
• Intuitive operation : click-based control that guarantees repeatable adjustments by any user.

Use cases

• Retail and hospitality : rooms, covered terraces, private rooms and corridors.
• Education and offices : classrooms, offices, common areas and reception.
• Centers of worship and culture : chapels, multipurpose rooms, museums.

Frequently Asked Questions

Is it suitable for low impedance speakers (4–8 Ω)?
No. It's a controller for 100V line systems . Specific solutions are required for low impedance.

How do I install it?
It is recessed into a standard wall box . The 100V amplifier output cable enters the Wall 50 and from there powers the zone's speaker line.

How many speakers can I connect?
Add up the tap power of each 100V speaker in the zone and make sure you do not exceed 50W total managed by the Wall 50.

Project description

Audibax Wall 50 wall-mounted volume control for 100V line , 50W , 11-position rotary selector, flush- mounted in standard junction box, dimensions 86 × 93 × 66 mm , white . For use in zoned background music/public address systems.
