AKG PCC170 - PCC170 Boundary Condenser Microphone with Cardioid Polar Pattern

AKG PCC170 - Supercardioid condenser boundary microphone for conferences, podiums, and boardrooms

The AKG PCC170 is an electret condenser boundary layer microphone designed to capture speech with high intelligibility at meeting tables, lecterns, courtrooms, and conference spaces. Its capsule works very close to the surface to maintain phase coherence ( PCC ) and minimize comb filtering and feedback. It offers a supercardioid polar pattern (half-supercardioid in the upper hemisphere) , a wide 50 Hz–20 kHz response, and a sensitivity of 22 mV/Pa , with an equivalent noise floor of 22 dB-A and a maximum SPL of 120 dB . It operates on 12–48 V phantom power and is output on a Switchcraft TB3M connector with a detachable 4.6 m mini XLR (TB3F) to XLR male cable. It features a 3-position Bass-Tilt switch to adjust the bass (compensate for table effect or reduce subsonic noise) and RFI suppression for stable operation with mobile devices. All this in a robust 123 x 86 x 23 mm , 170 g body with a rubberized base for quiet support.

Main features

• PCC Surface Design : Near-table element for phase coherence and improved gain-before-feedback.
• Supercardioid pattern (half-supercardioid on the surface) that reduces ambient noise and off-axis spotlights.
• 50–20,000 Hz response with 3-position Bass-Tilt switch for bass shaping.
• 12–48 V phantom power ; electronics with RFI suppression to prevent RF interference.
• Professional connectivity : Switchcraft TB3M output and detachable TB3F → 4.6m male XLR cable.
• Low self-noise (22 dB-A) and max. SPL 120 dB for clear voice with wide dynamic range.
• Compact construction : 123 × 86 × 23 mm; 170 g ; base with rubber feet for mechanical decoupling.

Benefits for voice applications

• Superior intelligibility on tables and lecterns thanks to surface pickup and directional pattern.
• Less feedback and less room noise pickup compared to conventional omnidirectional or table microphones.
• Clean and quick setup : place it within arm's length of the speaker, connect phantom power, and you're done.
• Adaptable sound with Bass-Tilt to match the bass to the furniture and speaking style.
• Universal compatibility with mixers and XLR interfaces thanks to standard phantom power.

Use cases

• Conference tables and videoconferences with several speakers.
• Lecterns and pulpits in auditoriums, plenary halls and universities.
• Courtrooms and committee rooms that require clear and discreet recording.
• AV rental and fixed installations in hotels, convention centers, and corporations.

Frequently Asked Questions

• Power required? Yes, 12–48 V phantom power from the table/interface.
• Can it be partially hidden? Yes; because it's surface-mounted and low-profile, it can be discreetly placed on the table without losing its brightness.
• Does this include a standard XLR cable? Yes, a 4.6m mini XLR (TB3F) to male XLR cable is supplied.

Description for projects

AKG PCC170 electret condenser boundary microphone, supercardioid pattern (half-supercardioid), response 50 Hz–20 kHz , sensitivity 22 mV/Pa (−30 dBV) , noise eq. 22 dB-A , SNR 72 dB-A , max. SPL 120 dB , impedance 150 Ω , phantom power 12–48 V , Switchcraft TB3M output with TB3F → XLR male cable 4.6 m , dimensions 123 × 86 × 23 mm , weight 170 g , black finish.
