dbx 640M – 6x4 Digital Zone Processor

In stock
SKU: 640M EAN13: 691991401169
(0)
1.378,94 € inc. VAT

If you have any questions about this product, we can assist you by filling out the contact form

Ask an expert

Chat Email +34 621046470
The ZonePRO 640m offers fixed I/O, a pre-configured architecture, configurable insert processing, and optional duplication of audio channels to another ZonePRO device via a link bus. The 640m features a total of six inputs and four outputs. Inputs include four balanced terminal block mic/line switching inputs and two mono-summed pairs of unbalanced RCA inputs. A hardware microphone gain control allows microphone gain to be adjusted per channel. The 640m has a pre-configured architecture with input processing, a core matrix, and output processing. Two input insert positions and one output insert position allow channel-specific insert processing to be configured. AutoWarmth®, a psychoacoustic feature that maintains full frequency bandwidth even when the signal level has dropped, is permanently available in each output zone. A link bus allows duplication of the first six audio channels to another ZonePRO device in applications where additional output zones are required. The 640m’s front panel features comprehensive signal metering, an informative LCD display, and user-specified front-panel control. Additional system control is offered in the form of optional Zone Controllers. This collection of hardware wall controllers represents a series of simple and elegant user interfaces for functions such as volume, source, and preset control. All ZonePRO devices can be controlled by third-party control systems via RS-232 or Ethernet as appropriate (see table for details). The Setup Wizard within ZonePRO Designer guides users through the 640m’s step-by-step configuration process. Features: 6 Inputs / 4 Outputs: 4 Balanced Mic/Line Inputs: 2 pairs of unbalanced, mono-summed RCA inputs? Microphone gain per channel? Preconfigured architecture? Two configurable input insert positions? One configurable output insert position? AutoWarmth® per output zone? Link bus? Integral signal metering? Front-panel LCD? User-specified front-panel control? Optional ZC controllers? Ethernet control? Serial control? Third-party control? Wizard-driven setup
  • Brand:dbx
  • Model:ZonePRO 640m
  • Family:ZonePRO
  • Total entries:6 (4 × balanced mic/line in Euroblock; 2 × unbalanced RCA pairs,mono-sum)
  • Departures:4 × electronically balanced Euroblock
  • Mic Gain (per channel):30–60 dB
  • Phantom microphone:+15 V DC
  • EIN (previous micro):< −118 dBu (22 Hz–22 kHz, 150 Ω)
  • Input impedances (Euroblock):> 50 kΩ bal. / > 25 kΩ non bal. (RF filtered)
  • Input impedance (RCA):> 25 kΩ (non-bal., RF filtered)
  • Maximum input levels:+20 dBu (mic/line); +12 dBu (RCA)
  • Output impedance/level:120 Ω (bal.) / 60 Ω (non-bal.); max. +20dBu
  • A/D Conversion:dbx Type IV™; DR line > 113 dB (Aw) / > 110 dB (unweighted)
  • D/A Conversion:DR 112 dB (Aw) / 109 dB (unweighted)
  • Sampling rate:48 kHz
  • System performance:DR > 109 dB (Aw);THD+N 0.003%typical at +4 dBu/1 kHz; response 20 Hz–20 kHz (±0.5 dB)
  • Propagation delay:0.6 ms
  • Crosstalk:> 80 dB (interchannel and input-output)
  • Highlighted Features: Mix Functionality,ANC(Ambient Noise Compensation),AutoWarmth®, EQ, bandpass/crossover filters, compressor/limiter, delay, polarity inversion
  • Architecture:Preconfigured with 2 inserts per input and 1 per output; central matrix
  • Link Bus (duplication):TicketsML1, ML2, S1, S2towards another unit
  • Control:Ethernet and RS-232 via ZonePRO Designer; compatible with ZC wall controllers and third-party controls
  • Frontal:Informative LCD and 4 6-segment output meters (−30 to +20 dBu)
  • Dimensions (H × W × D):45 × 483 × 197 mm (1U)
  • Weight:2.74 kg (shipping weight 4.0 kg)
  • Consumption:29 W;BTU:< 92.13
  • Certifications:UL 60065, IEC 60065, EN 55013
  • Type Audio
  • Vendor DBX
  • SKU 640M
  • Bar-code 691991401169
